Wheel loader 2ton YN926
- 300 Unit / Units per Month
- Qingdao
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
Condition | New | Brand Name | YINENG | |
Model Number | YN926 | Place of Origin | Shandong, China | |
Type | Front Loader | Moving Type | Wheel Loader | |
Dimension(Long * Breadth * High) | 5880*2060*2750MM | Rated Load | 2000KG | |
Certification | GOST;CE;ISO | Warranty | Half year | |
After-sales Service Provided | Overseas service center available |
Product Description
Specifications
Bucket capacity 1.1m3;Rated load 2000kg; Dumping height 2750mm; 60KW; YTO EngineBucket capacity 1.1m3;Rated load 2000kg; Dumping height 2750mm; 60KW; YTO Engine
1- FEATURES:
* YTO diesel engine is adopted, with strong power.
* Applying hydrodynamic transmission technology, single stage, 3 elements torque converter owns simple structure and high reliability.
* Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operation easy.
* Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
* Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
* Load sensing fully hydraulic steering system makes operation easy.
* Air over hydraulic brake system; Caliper disc brakes.
* Working device with automatically levelling ability at high position.
*Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
* Integral, luxury instrument board.
* New, luxury cabin.
OPTIONAL:
Original Cummins engine.
(Model: B3.3TAA-C80, Euro III emission)
Cummins engine
(Model 4BTA3.9-C100, from Dongfeng Cummins Co.)
Lovol Engine, with Perkins Technolgy
(Model:1004-4L06, From Tianjin Lovol Engine Co.)
Electric controlled gear-shift.
Air Condition
Joystick
Quick Hitch (Fork)
ROPS Cabin
*CE Approved.
*Obtained the certificate of ISO9001:2000;
*Manufacturing license number: TS2510025-2009.
2- SPECIFICATIONS:
Item | Specifications | Item | Specifications |
Bucket capacity | 1.1 m3 | Min. turning radius (outside of rear wheels) | 4600mm |
Rated load | 2000 kg | Steering angle | Each direction 35º |
Dumping height | 2750 mm | Min. ground clearance | 320mm |
Dumping reach | 920 mm | Wheel base | 2350mm |
Boom lifting time | 5 S | Tread | 1500mm |
Total cycling time | 9 S | Engine model | YTO LR4018G |
Max. speed | 25km/h | Rated power | 60kW/2400rpm |
Max. breakout force | 55 kN | Tyre | 16/70-20 |
Max.drawing force | 45 kN | Overall dimensions | 5880*2060*2750mm |
Max. Gradeability | 30° | Operating weight | 6000kg |
