CNC Pipe Threading Lathe QK1320A3SF

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port shenzhen
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Turning Center
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	640MM	Place of Origin	Guangxi, China
Brand Name	xiashi	Model Number	QK1320A3SF
Dimension(LWH)	4200x2000x2000mm	Weight	5.8 ton
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

CNC Pipe Threading Lathe QK1320A3SF

CNC pipe threading lathe Three gears Servo frequency speed
technical parameters		QK1320A3SF
center distance (mm)		1500	3000
max. swing over bed (mm)		dia 640
width of the bed (mm)		550
spindle bore diameter (mm)		dia 200
tube outside diameter (mm)		dia 60~dia 190
max. swing over crossslide (mm)		dia 330
spindle taper		ME dia 202/1:50
Servo spindle speed (r/min)		6~30/20~120/80~450
Servo main motor power (KW)		15KW/50Hz
chuck OD/ ID (mm)		dia 500/dia 200
three-jaw chuck (mm)		K11-dia 500D
distance between two chucks (mm)		1600
inch thread range and number of species (thread per inch)		0.1~254
metric thread range and number of species (mm)		0.1~400
Z axis	max. travel (mm)	1400	2900
	travel speed (m/min)	4~6
	min. travel unit (mm)	0.001
	repeatability accuracy (mm)	0.025
X axis	max. travel (mm)	380
	travel speed (m/min)	3~5
	min. travel unit (mm)	0.001
	repeatability accuracy (mm)	0.016
tail stock	sleeve diameter (mm)	dia 115
	sleeve taper	MS 6#
	sleeve travel (mm)	270
arbor cross-section size		32×32
electric tool post		four-station LDB4-120(6163A) toolpost of square turret: 240×240mm
overall dimensions (L×W×H) (mm)		4200×2000×2000	5900×2000×2000
GrossNet weight (ton)		5.8/5.6	6.8/6.6

The usual brand-name accessories:
1) precision bearing NSK, imported from Japan;
   2) Famous brand auto centralized lubricating system;
   3) Famous brand Servo spindle motor;
   4) famous brand electric tool post;
   5) famous brand encoder;
   6) famous brand ball-screw;
   7) low-voltage apparatus of Siemens and France Schneider;
   8) domestic brand-name machine tool accessories;
  9)the famous brand lighting and cooling system;
10) Famous brand Hand - held electronic pulse wheel

Optional CNC system of famous brand:
1) Siemens 802D SL servo
2) Japan FANUC 0i-mate-TD servo
3)Guangzhou CNC GSK980TDb servo
