Home > Products > Grinding Machine > M2120A metal internal grinding machine with high quality
M2120A metal internal grinding machine with high quality
- Shenzhen Shanghai Guangzhou Qingdao
- T/T L/C D/P D/A Credit Card
You May Like
-
surface grinding machine price list MY7132x20
-
high precision surface grinder, surface grinding machine MY7132x20
-
Vertical Spindle Die Grinding Machine with Rotary Work Table MD74160K
-
Vertical Spindle Surface Grinding Machine with Rotary Work Table M7475K
-
CNC Cylindrical Grinding Machine MK1320
-
Dependable Performance Dovetail Guideway Grinding machine Y2-1003A,Grinder With Low Price
Product Details
| Condition | New | Type | Internal Grinding Machine | |
| CNC or Not | Normal | Max. Grinding Diameter | 50-200mm | |
| Max. Grinding Length | 200mm | Place of Origin | Guangxi, China | |
| Brand Name | Xiashi | Model Number | M2120A | |
| Voltage | Customized | Power(W) | 8.6kw | |
| Dimension(L*W*H) | 3100*1450*1470 | Weight | 3400kg | |
| Certification | CE ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
M2120A metal internal grinding machine with high quality
Feature
1 grindind hole dia :50-200mm
2 grinding depth:200mm
3 working piece speed:100-500r/min, stepless
4 roughness:0.32Ra
Specification
Machine Model | M2120A | |
Dia.to be ground(mm) | 50-200 | |
Max. depth to be ground(mm) | 200 | |
Rotating dia.(mm) | inner hood (mm) | 400 |
Outer hood (mm) | 600 | |
Max. rotating angle of machine head (°) | 30° | |
Workpieces speed (r/min) | 100-500 (stepless) | |
Wheel speed (r/min) | 4000-60008000-11000 | |
Machine total power (kw) | 8.6 | |
Workpiece motor power (kw) | 2.2 | |
Wheel motor power (kw) | 4 | |
Machine size (mm) | 3100*1450*1470 | |
Machine weight (kg) | 3400 | |
Machine power source | 3N-50HZ 380V | |
Working accuracy | Bore roundness (mm) | 0.003 |
Bore cylindricity(mm) | 0.008 | |
Bore surface roughness | 0.63Ra | |
Picture for your reference
Packing&Delivery&Terms of Payment
We use wooden package to protect the equipment in container.
Why Choose Us?
- We have our own factory and strong production capacity.
- we insist on good quality and have strict quality standards
- The hiring of experienced staff to guarantee high quality.
- Our product can be made as per your requirement .
- 24 hour online communication for you.
- We have more than 6 years of export experience.
FAQ
Q: What information should I let you know, if I want to get a product offer?
A: 1. the size of your work piece
2. the CNC system you preferred if you need CNC type
3. the work piece drawing if you have
Q: How to control the quality of production processes?
A: We have a professional quality inspectors to check on the quality of the finished product.
Q: Is it possible to visit your factory?
A: It is very convenient to visit us and all clients from around the world are highly welcomed.
Q: What’s the MOQ?
A: The MOQ is 1 set.
Q: What’s the quality assurance and service ?
A: We offer one year warranty and 100% quality inspection before shipment. We shall reply your message within 24 hours to solve your problem.
