cnc boring milling machine with cnc cutting machine for metal T7240
USD $100 - $1,000
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- SHENZHEN
- T/T Credit Card
You May Like
-
High precision and high quality motorcycle cylinder boring machine T7240
-
TM807A Motorcycle Cylinder Boring and Honing Machine Vertical Cylinder
-
Cylinder boring & Honing machine TM807A
-
T8590 Gas Valve Seat Boring Machine
-
20-90mm boring dia. gas valve seats boring machine with low cost T8590
-
Xia Shi boring machine for Gas Valve seats T8590A
Product Details
| Condition | New | Place of Origin | Yunnan, China | |
| Brand Name | XIASHI | Model Number | T7240 | |
| Type | Horizontal | CNC or Not | CNC | |
| Voltage | Depends on model | Power(W) | 5.5kw | |
| Dimension(L*W*H) | 2281x2063x3140mm | Weight | 2200kg | |
| Certification | CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
cnc boring milling machine with cnc cutting machine for metal T7240
The utility model relates to a digital control (CNC) driving device for the vertical and horizontal movement of the worktable. The machine is mainly used for fine boring and milling processing various types of automobile, tractor, motorcycle cylinder hole, cylinder hole, cylinder end, workpiece surface and manufacture requirements of hole parts and milling precision of different materials.
| name | specification | |
| 1 | Carriage travel | 800mm |
| 2 | spindle speed | 0~1500r/min |
| 3 | spindle feed speed | 0~3000mm/min |
| 4 | Distance from spindle center to column guideway | 580mm |
| 5 | Distance from spindle center to slide | 510mm |
| 6 | worktable | 1100×500mm |
| 7 | Y axis travel | 1000mm |
| 8 | X axis travel | 400mm |
| 9 | Y axis feed speed | 0~3000mm/min |
| 10 | The min distance between the sliding face and the worktable | 375mm |
| 11 | the max distance between the sliding face and worktable | 1175mm |
| 12 | precision | IT7 |
| 13 | Machining roughness | R0.8~1.6 |
| 14 | position precision | 0.02mm |
| 15 | repeat position precision | 0.02mm |
