TK611C/1A CNC horizontal boring machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port SHENZHEN
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Place of Origin	Guangxi, China	Brand Name	xiashi
Model Number	TK611C/1A	Dimension(LWH)	543730202890 mm
Weight	4400kg	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

110 (130 spindle optional)
CNC rotary table (5, 1 & 0.001 degree indexing) .

With planer workbench, this machine adopts double sided power column frame structure form. It can achieve high feed processing and use herringbone guideway cover made especially suitable for basic big pieces of large and medium sizes and weights, the drills of many parts such as board pieces, disk parts, shell parts, mould and so on,processing of diffuser, hinge, boring hole, and milling processing of plate and curved surfaces.

Main specifications

Model	TK611B/1A	TK611C/1A	TK611C/4A
Spindle diameter	110 mm	110 mm	110 mm
Worktable size (L×W)	1320×1010 mm	1320×1010 mm	1320X1010 mm
Max. loading of worktable	5000 Kg	5000 Kg	5000 Kg
Distance from spindle center to table	5-835 mm	5-835 mm	5-1135 mm
Longitudinal and transverse travel of table (z x)	1300×850 mm	1300×1200 mm	1300×1800 mm
Headstock vertical travel (y)	830 mm	830 mm	1130 mm
Spindle axial travel (w)	550 mm	550 mm	550 mm
Max. boring diameter	240 mm	240 mm	240 mm
Max. drilling diameter	50 mm	50 mm	50 mm
Max. machining diameter with facing plate	630 mm	630 mm	630 mm
Facing head tool holder’s radial travel	160 mm	160 mm	160 mm
Inner hole taper of spindle	ISO No. 50	ISO No. 50	ISO No. 50
Facing plate speed range	4-125 rpm	4-125 rpm	4-125 rpm
Spindle speed range	12-1100 rpm	12-1100 rpm	12-1100 rpm
Facing head feeding speed range	0.2-330 mm/min	0.2-330 mm/min	0.2-330 mm/min
General power of machine	35 KVA	35 KVA	35 KVA
Positioning accuracy (x, y, z) (B)	X:0.04 Y:0.032 Z:0.04 mm 15"	X:0.04 Y:0.032 Z:0.04 mm 15"	X:0.04 Y:0.04 Z:0.04 mm 15"
Repeated positioning accuracy (x, y, z/B)	0.015 mm / 6"	0.015 mm / 6"	0.015 mm / 6"
Overall dimensions (L×W×H)	5437×2670×2890 mm	5437×3020×2890 mm	5352×3704×3344 mm

Detailed pictures for your reference

If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
