Product Details

EDM MACHINE
Adopting high precision DC servomotor
With the function of PC hand wheel,it is easier to remove the machine

EDM MACHINE

	specification	EDM250	EDM300	EDM350	EDM400	EDM450	EDM500	EDM700
Parameter		EDM250	EDM300	EDM350	EDM400	EDM450	EDM500	EDM700
working table (mm)		280×450	300×450	350×630	400X700	450X700	500X800	700×1200
working groove mm		800×490×280	890×530×320	980×650×350	1050X720X400	1210X770X450	1450X920X500	2000×1100×550
X axis travel mm		250	300	350	400	450	500	700
Y axis travel mm)		200	200	250	300	350	400	600
Z axis travel (mm)		200	200	300200^*	200	200	200	300
Work head travel (mm)				200	250	250	250	350
Chief axis connectboard to working table (mm)		540	580	600700	700	650	750	1100
Max.electrode weight (kg)		30	50	50	75	75	100	200
piece weight (kg)		200	300	500	650	650	850	2000
Overall dimension of workfluid container		1390×1480×2100	1390×1480×2100	1440×1460×2225	1450X1600X2100	1560X1600X2165	1810X1500X2295	1855×1410×2550
Net weight of machine (kg)		1000	1200	1300	1800	1800	2000	3800
Max.machining current		40	60	60	80	80	80	1500
Max.machining current (mm³/min)		400	500	500	800	800	800	1500
Minrate of electorode wear		≤0.2%	≤0.2%	≤0.2%	≤0.2%	≤0.2%	≤0.2%	≤0.2%
Optinum roughnessum		Rα0.3	Rα0.3	Rα0.3	Rα0.3	Rα0.3	Rα0.3	Rα0.3
Item no .		161010	161012	161014	161016	161018	161020	161022
