ISO Certificate of the PCL series shaft impact crusher rock sand make machine ,sand making

  PCL sand making machine is of high-power and low-consumption, which is designed depending on several year's hard work and study of mechanical mining equipment. This type sand maker absorbed the advanced technology of the same products of Barmac Company of America, and now is of the international level. It plays an important role in crushing minerals into pieces. Since the sand processing machine was put into production in 2000, AMEC has achieved good market share in domestic market, and product performance is tending toward best perfection, deeply trusted by customers. PCL sand making machine, namely Vertical Shaft Impact Crusher, is widely used in all kinds of mineral, cement, corhart, carborundum grain, glass raw material, machine making construction sand, stone stock and all kinds of metallurgy slag, especially carborundum, sintered bauxite, magnesite, and materials with features of very hardness and anticorrosion. And this and making equipment is more productive than other kind of sand&stone crushers.

Raw Materials:

Limestone, river pebble, rocks, bluestone, cobblestone, weathered sand, basalt, granite, quartz, diabase

Application:

Mmine, cement, fire-proof materials, bauxite, corundum, glass raw material, building sand, stone materials and other metallurgy slag

Advantages of PCL Sand Making Machine:

1. Unique Lining significantly decreases wear parts cost and maintenance workload. During the process, the stone rock can form a protective bottom layer which makes the equipment more durable.

2. Adopting high-quality wear-resistant materials at home and abroad leads to long service life. Hard wear-resistant material, small volume, light weight, easy to replace.
3. Bearing special installation and advanced spindle design, with characteristics of heavy load and high speed rotation, without any problem in fine crushing and coarse grinding.
4. Final products are cubic shape, high density and low iron pollution, and can be used as stone shaping machine.

Working Principle of PCL Sand Making Machine:

Material from the hopper falls into sand crusher, and will be divided into two parts by the distributor. One part falling into the high-speed rotation impeller through the middle and accelerated rapidly within the impeller. That acceleration can be up to several hundred times the acceleration of gravity, then projecting out from three uniform impeller flow channel at speed of 60-70 m / s; another part of the material falls freely from all around the feeder, impact on the vortex branch cavity lining, and then will be bounced back to the top of vortex chamber, the movement direction would be changed to start moving down on the diagonal; materials emitters from the impeller form a continuous material curtain. Thus, materials will be hit, rubbed and grinded twice or several times in whirl crushing cavity. Finally crushed materials discharge from the lower discharge port. Throughout the crushing process,materials impact and crush each other , not in direct impact on the metal element, but only shock ,rub and grind the lining, thus prolonging mechanical life.

Specification and Technical Parameter :

Nude packing for the main machine

Wooden case for the power motor and spare parts

    We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support  and after service.
