1T Double Wheel Wire Rope Pulley Block Snatch Block
- SHANGHAI
- T/T Money Gram
You May Like
Product Details
| Type | Other, Other, double pulley block | Material | Other, Other, Steel | |
| Place of Origin | Jiangsu, China | Brand Name | XINYA | |
| Model Number | SHC |
Product Description
1T Double Wheel Wire Rope Pulley Block Snatch Block
Application
1T Double Wheel Wire Rope Pulley Block Snatch Block is for lifting.It can be used in single, also can be used as a block.
Characteristics
1.Material: Aluminum alloy
2.Single wheel opening hook type.Two or three sheaves are closed.
3.It is light weight using the aluminum alloy.
Technical Data
Order number | Model | Number of sheaves | Rated load (kN) | Outside diameter×width(mm) | Weight (kg) | Hoisting point type | ||
11101 | QH1GN-1K | 1 | 10 | Φ100×31 | 1.8 | G | H |
|
11102 | QHN1-2 | 2 | 10 | Φ80×27 | 1.8 | G | H |
|
11103 | QHN1-3 | 3 | 10 | Φ80×27 | 2.1 | G | H |
|
11111 | QHN2-1K | 1 | 20 | Φ120×35 | 2.2 | G | H | B |
11112 | QHN2-2 | 2 | 20 | Φ100×31 | 2.6 | G | H |
|
11113 | QHN2-3 | 3 | 20 | Φ100×31 | 3.7 | G | H |
|
11121 | QHN3-1 | 1 | 30 | Φ150×39 | 3.4 | G | H | B |
11122 | QHN3-2 | 2 | 30 | Φ120×35 | 4.5 | G | H |
|
11123 | QHN3-3 | 3 | 30 | Φ100×31 | 4.6 | G | H |
|
11131 | QHN5-1K | 1 | 50 | Φ166×40 | 5.2 | G | H | B |
11133 | QHN5-2 | 2 | 50 | Φ150×39 | 5.5 | G | H |
|
11134 | QHN5-3 | 3 | 50 | Φ120×35 | 5.1 | G | H |
|
11141 | QHN8-1K | 1 | 80 | Φ205×49 | 7.2 | G | H | B |
11142 | QHN8-2 | 2 | 80 | Φ166×40 | 8.3 | G | H |
|
11143 | QHN8-3 | 3 | 80 | Φ150×39 | 7.9 | G | H |
|
11151 | QHN10-1K | 1 | 100 | Φ246×60 | 11.4 | G |
| B |
11152 | QHN10-2 | 2 | 100 | Φ166×40 | 10.2 |
| H |
|
11153 | QHN10-3 | 3 | 100 | Φ150×39 | 11.7 |
| H |
|
11161 | QHN15-1K | 1 | 150 | Φ280×65 | 12.1 |
|
| B |
11162 | QHN15-2 | 2 | 150 | Φ205×49 | 12.8 |
| H |
|
11163 | QHN15-3 | 3 | 150 | Φ166×40 | 11.8 |
| H |
|
11164 | QHN15-4 | 4 | 150 | Φ150×39 | 13.9 |
| H |
|
·uses :applied in line construction to craning weight ,etc.
·Features: to adopt aluminum alloy side panel and MC nylon sheave .so it is light .monosheave block is open.
