Overhead Power Line Stringing Equipment SA-YQ60 Hydraulic Puller

FOB Price

USD $40,000 - $60,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	Xinya
Model Number	SA-YQ60		Type	Other, Hydraulic puller

Overhead Power Line Stringing Equipment SA-YQ60 Hydraulic Puller

Essential parameter

Maximum linepull (kN)	60
Continuous linepull (kN)	50
Maximum linespeed (km/h)	5
Bullwheel bottom of groove diameter(mm)	Φ460
Bullwheel grooves number	7
Maximum suitable steelrope diameter (mm)	Φ18
Maximum through connector diameter (mm)	Φ60
Engine power /speed (kW/rpm)	77/2800
Dimensions (mm)	3800×2100×2300
Weight (kg)	3000

Feature :

1. infinitely variable speed and linepull control ,the pull in the rope can be read on the line pull gauge .

2. the max pull for conductor–stringing operation can preset ,automatic overpull protection system .

3. spring applied –hydraulic release brake acts automatically in case of hydraulic failure ensure to safety .

4. attached reel winder with automatically level wind .load and unload conveniently

Mian component :
