chinese mini farm tractor,garden tractor
USD $5,000 - $20,000
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Qindao
- Credit Card
You May Like
-
2015 for sale!chinese 4*4 35hp wheel farm tractor,garden tractor
-
chinese factory direct supply 4*4 40hp wheel mini farm tractor with low price
-
chinese cheap 25hp 4*2 wheel small tractor,farm tractor,garden tractor
-
2015 china factory supply 30hp 4*2 wheel garden tractor with low price
-
chinese new condition 35hp 4*2 wheel mini farm tractor for sale
-
2015 best sell!chinese factory direct supply 4*2 40hp wheel mini garden tractor for sale
Product Details
| Condition | New | Type | Wheel Tractor | |
| By wheel | 4WD | Usage | Garden Tractor | |
| Drive Type | Gear Drive | Power(W) | 18.5KW | |
| Certificate | Other, ISO,CE | Brand Name | WOLWA | |
| Model Number | GN254 | Place of Origin | Shandong, China | |
| After-sales Service Provided | Overseas service center available |
Product Description
chinese mini farm tractor,garden tractor
Product Description
specifications:
1.25HP
2.Drive type:4WD
3.Single stage cluth
4.Power steering
5.(8F+2R)gear box
6.Position adjustable lifter
7.Differential lock
8.Dual speed PTO
9.Three-point suspension
10.Front bumper
11.Rear-view mirror
| Model | GN250 | GN254 |
| Drive Type | 4×2 | 4×4 |
| Engine | ||
| Engine Model | FD295TA | |
| Engine Type | inline,vertical,water-cooled,four-stroke | |
| Cylinder diameter(mm) | 95 | |
| Stroke(mm) | 115 | |
| Max Torque(N·m)/Revolving Speed(rpm) | ≥96.8/≤1575 | |
| Displacement(L) | 1.63 | |
| Fuel Tank Capacity(L) | 51 | |
| Engine Rated Power (kW/rpm) | 18.5 | |
| Rated Operating Conditions Fuel Consumption Rate(g/kW·h) | ≤250 | |
| Drive Train | ||
| Clutch | Dry,single-stage | |
| Standard PTO speed(rpm) | (540,1000)/(750,1000)/(540,750) | |
| Gears | 8F+2R/10F+2R | |
| Speed range(Km) | 2.24~28.61 | 1.73~22.04 |
| Steering type | mechanical steering | hydraulic steering |
| Gear Shift Mode | sliding gear shift | |
| Break System | ||
| Service Brake | pedal,mechanical drive,closed shoe type | |
| Parking Brake | locked pedal | |
| Hydraulic System | ||
| Hydraulic Output Flow(L/min) | 30 | |
| Hydraulic Output Valve | 1 way(optional) | |
| Working Device | ||
| Three-Point Suspension | postposition,Category I | |
| Max.Lifting Capacity(kN) | ≥4.16 | |
| Tillage Depth Adjustment | position adjustable | |
| General Parameter | ||
| Overall Dimension(L×W×H)mm | With cab | / |
| Without cab | 3105×1430×2090 | |
| Wheelbase(mm) | 1705 | 1755 |
| Min. operating weight(kg) | With cab | / |
| Without cab | 1340 | |
| Min. Ground Clearance(mm) | 420 | 335 |
| Min.turning radius(mm) | 2800 | 3000 |
| Maximum Pull(KN) | 5.88 | 7.35 |
| Front Tire | 4.0-16 | 6.0-16 |
| Rear Tire | 9.5-24 | |
| Optional Disposition | ||
| hydraulic steering | dual-stage clutch | |
| dual-stage clutch | shuttle gear(creeper gear) | |
| shuttle gear(creeper gear) | swing draw bar | |
| swing draw bar | draft and positional lifter | |
| draft and positional lifter | rear counter weight | |
| ROPS with canopy | ROPS with canopy | |
| 1 group hydraulic output | 1 group hydraulic output | |
Our Services
Our Guarantee:
Service:
1.Excellent after-sale service teams
2.One year guarantee for the whole machine
3.General inspection on fixing before packing
4.Oversea service center acceptable
Quality control:
1.All products must go through checks before manufacturing process.
2.Every production line is equipped in an individual QC to ensure well-done production.
