Industrial High Speed Sawdust Charcoal Briquette Making Machine

1.charcoal molding machine

2.Mold your charcoal powder into briquette

3.Easy to operate and widely accepted

Sawdust Charcoal briquette making machine has been awarded 2 patents showing the features of high capacity, low energy consumption and durable and compact. Many performance data such as capacity, wood briquette density, electricity consumption and wearable degree has reached advanced level. Sawdust Charcoal briquette making machine can be used as charcoal powder briquette machine by replacement of some spare parts. The out diameter of finished briquettes is 50-80mm.

This machine is used to make sawdust into half-charcoal-stick. It is equipped with the auto -controlling heating system. The product of this machine can be used to heat boiler, fireplace, etc for warm in house. Using the inherent characteristics of wood raw materials, through the screw extrusion, high temperature, high pressure, the wood raw material to make micro-fiber lignin plastics combine to form a fuel rod

1. the prospect :

Charcoal / Biomass Briquette investment is a best project to generate revenue from forestry waste and to produce Green Energy to save the global environment. The awareness of using Eco-friendly & Non-conventional Bio-coal / Bio-fuel is increasing day-to-day due to the increasing of the conventional fuel cost.

This plant can make charcoal stick of different diameter and different shape from biomass and forest waste. Any type of Forestry waste can be used.

2.the raw material of charcoal could be :

Any types of forestry waste and forest waste can be used for make briquettes Such as maize stalks, soybean stalks, broomcorn stalks, cotton stalks, rape stalks, peanut plants, sunflower stalks, bamboo sawdust, bagasse , wood chips, rice husk, coffee husk, coir pith, jute sticks, groundnut shells, Bamboo, wood, straw dust, Mustard stalk and cotton stalks ,nutshell, coconut shell ,etc

3. the requirement of the raw material

diameter (size) :3-5mm ( if can not meet the requirement, it will need a crusher to crushing the raw material

moisture: 8-12%, (if can not meet the requirement, it will need a dryer)

no much impurity in the raw material

4. process of the whole production line of charcoal

The process for producing charcoal briquette as follow:
1. Crush the raw material into small pieces (diameter is about 3-5mm)
2. Dry the material by machine or dried it in the sun , till the moisture is less than 12%
3. Put the material into feed let of briquette machine
4. Produce the briquette stick from biomass material without any additive
4. Carbonized the briquette stic

Environment-protected Charcoal Briquette Press Machine

The whole charcoal production line mainly includes four needed machines: crusher, dryer, briquette making machine and carbonization furnace.

Sawdust Charcoal briquette making machine Picture

About packaging, for small size or single machine, we can offer free fumigation wooden case with steel frame, it not only can protect machine from damage, but also avoid checking when exporting.

For multiple machines or production line, it's better to loaded in standard container 20GP, 40GP, 40HQ, usually it needs wrapped with plastic firstly, then loaded in container.

we can offer EXW, FOB and CIF terms.

EXW: You arrange the shipping details from our factory to your port by yourself.

FOB: We arrange freight transport to Qingdao, Shanghai or other ports of China, then you arrange the shipping details from China port to your country port.

CIF: We arrange all shipping details to your country port, and ensure machines smooth arrival.

Kaifeng Rainbow Machinery Co., Ltd. is a domestic large-scale new energy environmental protection equipment manufacturers in China. The registered trademark is "Rainbow".

Our company has combined Research and Development, Production, Sales and Service in one, and our main product have Wood Crushing and Recycling Workstation, New Energy Particle Machinery, Feed Machinery, Organic Fertilizer Machinery, Broken machinery. Totally, have a lots of products, more than 300models, which make our company the most professional development and production of high-tech enterprises of new energy environmental protection machinery manufacturer in China.

1. Help you choose the most suitable machine.

2. Making the machine according to your request.

3. Give you machine’s details and video for help you use the machine more better.

4. One year warranty

5. Quality problem,we will send you the accessories.

6. Free repair whole using life without extra charge.

1. What's the delivery time?
We will deliver the product in 7 days after receiving the deposit.
2. What's your payment terms?
We can accept various payment terms if it is convenient for you.
3. what's your MAQ?
Our MAQ is 1 piece.
4. What's the lifetime of the wearing parts?
The material of our product is of high quality, and the lifetime of our wearing parts is twice longer than the others,including the roller skin, die and bearing.
5. What is your warranty?
12 months except the spare parts.
6. Will you send engineers to install the plant?
Of course yes,but at an extra cost will be paid by customers. Or you can get local contractors to do the commissioning and we send one supervising engineer.

7. Do you have some foreign customers using your equipments?
 Yes , we have customers all over the world.
