MITECH MT150 Ultrasonic Thickness Gauges with 4.5 digits LCD with EL back light 0.75~300mm

Specifications

It's a digital ultrasonic thickness gauge w/ highly accurate reading results. Based on same operating principles as SONAR, the instrument is capable of measuring thickness of various materials w/ accuracy as high as 0.1mm.

2-Point calibration function (Probe-Zero & Sound-Velocity) allows greater accuracy over small ranges by calculating the probe zero & velocity.

Suitable for measuring  wide range of materials including metals, plastic, ceramics,composites, epoxies, glass & other ultrasonic wave well-conductivematerials.

Applicable for different types of transducer models for special application, including coarsegrain material & high temperature applications (NOTE: 1 transducer is included in the set).

Features:

• Economical model
• Compatible for different probes
• High accuracy
• Low-power design
• 2-Point Calibration function:  Probe-Zero & Sound-Velocity
• 2 work modes: Single point & Scan mode
• Battery & Coupling status indicators
• Auto sleep and auto power off function to conserve battery life
• Memory function: data save, recall or delete
• Beeping Alarm, on each measurement or the measured value exceeds the tolerance limit
• EL Backlight: work conveniently even in dark areas
• Allows system reset to restore factory defaults
• Segment LCD
• 2 years guarantee
• CE certificate, Passed the European Directive Standard


Specifications:

• Display : 4.5 digits LCD with EL backlight
• Measuring Range : 0.75~300mm (in Steel)
• Sound Velocity Range : 1000~9999 m/s
• Resolution :  0.1mm
• Accuracy : ±0.5%Thickness + 0.04mm, depends on materials and conditions
• Units : mm or in for thickness value; m/s or in/μS for sound velocity
• Four measurements readings per second for single point measurement, and ten per second for Scan Mode
• Memory for up to 20 files (up to 99 values for each file) of stored values
• Transducer :
• Frequency : 5MHz
• Diameter : 10mm
• Measuring Range : 1.2 ~ 230.0mm (In Steel)
• Lower Limit : Φ20 ~ 3.0mm
• Description : Normal Measurement
• Operating Temperature : -20 ~ 60°C
• Storage Temperature : -30 ~ 70°C
• Relative Humidity : ≤90%
• Power Source : 2 x AA 1.5 Volt alkaline batteries
• Battery Life : 100 hours typical operating time (EL backlight off)
• Outline dimensions : 150mm × 74mm × 32mm
• Weight : 245g

Set Includes:

• 1 x Main Unit (Model No.: MT150)
• 1 x Transducer (Model No.: N05/90°)
• 1 x Couplant
• Plastic Carrying Case
• English Operating Manual
• 2 x AA 1.5V Alkaline battery



• Optional Items (not included in set):
  Please inform us if you want any of the following optional items to be included in your order.

• Optional Transducer
