Bluetooth Rfid Reader Supporting Windows and Andriod System

FOB Price

US$ 90 - 122 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

HCT

Model Number

HCT-BLTR-10100

Specifications – 134KHz RFID LF Bluetooth Reader

Frequency	134.2KHz (ISO11784/5 OR TI Standard)
Reading Distance	0 to 7 CM
Size(mm)	82 x 52.3 x 25.8
Weight	< 98 g
Communication Interface	Wireless Bluetooth; USB
Antenna Connection	Built-in
Bluetooth Transmission Distance	> 10 M
Reading Time	0.1 S
Power Consumption	<0.8 W
Operating Voltage	DC 3.7 to 4.2 V
Bluetooth Standard	Class Two
Communication Baud Rate	9600 bps
Re-chargeable Lithium Battery	950mAh, DC3.7V
Humidity	5% to 90% relative
Operating Temperature	-20°C to 65°C
Storage Temperature	-25°C to 85°C

Main Features – 134KHz RFID LF Bluetooth Reader

Wireless data transferring via the Bluetooth connection
Can work with WinCE 5.0 or Windows Mobile 5.0/6.0 based SmartPhones or PDAs (Bluetooth featured)
Palm sized
Long battery life - continuously reads tags for up to 7000 times per charge
