RF EAS Antenna System XLD-T06

RF EAS Antenna System

Model No.: XLD-T06 Acrylic RF system/ Wide Aisle RF System

Description:

The wide aisle system is specially designed to ensure superior detection for wide aisle installations
The detection range can be up to 2.0m (6ft) with the appropriate 8.2MHz labels or tags
The childproof design of the wide aisle shows an overall appearance which is both pleasing and robust
The wide aisle is fitted with the latest optically (wired) slaved transmitter and a receiver using sophisticated digital signal processing
This ensures that the signal of disposable labels (hard-tags) can be reliably distinguished from potential noise sources and guarantees maximum detection performance, yet minimizing false alarms
The system is fully compatible with all 8.2MHz hard tags and disposable labels
For retailers to whom maximum system detection range is critical, along with contemporary appearance, the newly designed wide aisle is definitely the system of choice

Electrical specifications:

Operating frequency: 8.2MHz ( ±10% )
Synchronization input: 1 x Opto receiver (plug in, optional)
Synchronization output:2 x Opto transmitter (plug in, optional)
Receiver technology: digital signal processor (DSP)
Power supply: 24V DC/1.5A, linear power supply
Alarm light: light emitting diodes (LED)
Alarm sound: buzzer, 90dB at 1m (3.3ft)
Mechanical specifications: height 1,620mm (5.31ft)
Material: clear acrylic
