1KW Low Rpm VAWT Vertical Axis Wind Turbine Generator for Home Use With CE Certificate

FOB Price

Negotiable / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	JINFAN
Model Number	JFVC-1KW		Type	Wind Power Generator

1KW low rpm VAWT vertical axis wind turbine generator for home use with CE certificate

model	JFVC-1KW
the diameter of wind wheel (m)	2.2
material of blades	Fiberglass-Reinforced Plastics
blades number	5
blades length(mm)	1830
blades width(mm)	410
RPM(r/min)	50
rated wind speed(m/s)	10.0-11.0
start up wind speed(m/s)	2.5
working wind speed(m/s)	3.0-25.0
survival wind speed	40m/s
generator style	3-phase AC PM
protection generator case	IP54
material of generator case	cast iron/aluminium
rated power(w)	1000
the max power(w)	1500
rated voltage(v)	24/48V
the height of tower(m)	8
guy cable tower type(mm)	114*6
controller and inverter	charging controller and pure sin wave inverter
battery reference	12V100ah, 4pcs

Qingdao Jinfan Energy Science & Technology Co., LTD. is a professional wind generator manufacturer.

Our hot products have following four series:

1.Vertical axis wind generator:300W,500W,1KW,2KW,3KW,5KW

2.Vertical low RPM PMG:

300W80RPM,500W80RPM,1KW50RPM,1KW100RPM,2KW50RPM,3KW50RPM,3KW100RPM,5KW50RPM,5KW100RPM,10KW50RPM,10KW100RPM,15KW125RPM

3.Horizontal axis wind generator:300W,500W,1KW,2KW,3KW,5KW,10KW

4.Wind and solar hybrid (street lamp) system
