Home > Products > Vertical Axis Wind Turbine > Wind Generator Vawt 300W500W1KW2KW
Wind Generator Vawt 300W500W1KW2KW
- Qingdao/Shanghai
- T/T
You May Like
-
Low Speed 50rpm Vawt Permanent Magnet Generator 2kw
-
48V/96V Vertical Windmill Generator/2kw Electric Windmills With Low Noise for Home Use
-
Small Wind Generator 1kw / Low Rpm Alternator/vertical ac Pmg Price
-
1kw Vertical Wind Turbine Permanent Magnet Generator/low Rpm Vertical Pmg
-
Aeros Wind Power Generator/vertical Wind Turbine
-
300w Vertical Wind Generator
Product Details
| Place of Origin | Shandong, China | Brand Name | JINFAN | |
| Model Number | JFVC-300W | Type | Wind Power Generator |
Product Description
Specifications
wind generator vawt 300W500W1KW2KWlow noise
high safety
vertical axis small wind generator
wind generator vawt 300W500W1KW2KW
Parameter:
| model | JFVC-300W | JFVC-500W | JFVC-1KW | JFVC-2KW |
| diameter of wind wheel | 1.6m | 1.8m | 2.2m | 2.4m |
| blades material | fiberglass reinforced plastics | |||
| blades number | 5 | 5 | 5 | 5 |
| length of blades | 1120mm | 1650mm | 1830mm | 2160mm |
| width of blades | 360mm | 410mm | 410mm | 450mm |
| RPM | 80(r/min) | 80(r/min) | 50(r/min) | 50(r/min) |
| rated wind speed | 12m/s | 12 m/s | 14m/s | 14m/s |
| start up wind speed | 2m/s | 2m/s | 2.5m/s | 2.5m/s |
| work up wind speed | 3-25(m/s) | 3-25(m/s) | 3-25(m/s) | 3-25(m/s) |
| survival wind speed | 40m/s | 40m/s | 40m/s | 40(m/s) |
| generator type | 3 phase permanent magnet generator | |||
| proyection grade of generator | IP54 | |||
| generator material | cast iron | cast iron / Aluminum | ||
| rated power | 300W | 500W | 1KW | 2KW |
| max power | 350W | 550W | 1.2KW | 2.5KW |
| rated voltage (DC) | 12V/24V | 24V/48V | 24V/48V | 48V/96V/120V |
| tower height | 6m | 6m | 8m | 8m |
| cable tower type(mm) | 89*6 | 96*6 | 114*6 | 114*6 |
| controoler,inverter | wind & solar hybrid controller,sine wave inverter | wind & solar hybrid controller,sine wave inverter / on-grid controller and inverter | ||
| battery | 12V100ah, 2pcs | 12V100ah, 2pcs | 12V100ah, 4pcs | 12v150ah 4pcs/ 12V100ah 8pcs |
Note:
1.Concern Tower:
We can supply two kinds of tower for option, the advantage and disadvantage as follow:
(1).Guy cable tower: Cheapest tower. Cheaper delivery cost, light weight. But need more space and more concrete.
(2).Freestand tower: More beautiful. Need small area for foundation. No steel wire But a little expensive.
2. Concern controller/inverter:
(1).Optional by-pass function : The off grid system can have bypass function, that is to say grid switch function. When no wind, and battery no power, the inverter can switch to grid.Inverter has a build in switch to change from batteries to grid when the battery voltage is lower than rated voltage.
(2).Optional wind turbine low-voltage charge function, making full use of low wind power.
Our company:
Qingdao Jinfan Energy Science & Technology Co., LTD. is a professional wind turbine manufacturer. We have a strong research and development team. At present, our main products are
1.Vertical axis wind turbine:300W,500W,1KW,2KW,3KW,5KW
2.Vertical low RPM PMG:300W80RPM,500W80RPM,1KW50RPM,1KW100RPM,2KW50RPM,3KW50RPM,3KW100RPM,5KW50RPM,5KW100RPM,10KW50RPM,10KW100RPM,15KW125RPM
3.Horizontal axis wind turbine:300W,500W,1KW,2KW,3KW,5KW,10KW
4.Wind and solar hybrid (street lamp) system
