Pvc Air Hose / Pvc Spray Hose /high Pressure Pvc Gas Hose
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | huizhong | |
| Model Number | 1/4"-1 | Material | PVC | |
| Specification | 1/4"-1 | Length | 40m,50m,100m,etc | |
| Thickness | 2mm-5mm | Standard | ISO9001 |
Product Description
Specifications
pvc air hose / pvc spray hose /high pressure pvc gas hoseSize and thickness: standard or customized
Moq 2 tons
Free sample
pvc air hose / pvc spray hose /high pressure pvc gas hose
Specifications
High tensile synthetic yarn, single/double yarn braided or spiraled.
Cover: NR & SBR synthetic rubber,
Applications: Widely used for converying of air, inert gas water in mining, construction, engineering, shipbuding, steel production etc.
Reinforcement: High tensile synthetic yarn, single/double yarn braided or spiraled.
Cover: synthetic rubber, black, red, yellow and tube in colors etc.
Chatacteristics: Abrasion resistant, weather resistant and zone resistant. Its of pressure bearable, flexible, light in weight, anti-bending, less distortion and nice smooth surface.
Standard length: 50m, 100m
Temperature range:-20°C~+60°C(-4°F to +140°F)
Techinique parameter | ||||||
Size | I.D | O.D | Weave floor | W.P | B.P | Fix Length |
Inch | I.D. (mm) | O.D. (mm) | ( B ) | (MPa) | (MPa) | ( m ) |
3/16” | 5 | 12 | 1 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 100 |
1/4” | 6 | 13 | 1 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 100 |
5/16” | 8 | 15 | 1 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 100 |
3/8” | 10 | 17 | 1 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 100 |
1/2” | 13 | 21 | 2 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 100 |
5/8” | 16 | 25 | 2 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 100 |
3/4” | 19 | 29 | 2 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 50 |
1” | 25 | 36 | 2 | 1.5 ~ 2.0 | 4.5 ~ 6.0 | 50 |
1-1/4” | 32 | 42 | 2 | 1 | 3 | 30 |
1-1/2” | 38 | 51 | 2 | 1 | 3 | 30 |
2” | 51 | 65 | 2 | 1 | 3 | 30 |
