Factory Steel Structure Drawing Pre Engineered Steel Structure in Project

FOB Price

US$ 600 - 1,200 / Square Meter

25 Square Meters(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	WZH
Model Number	steel structure		Material	Other, Steel, H steel, C purlin, Z purlin,sandwich panel

factory steel structure drawing pre engineered steel structure in project

1. Brief instruction of the prefabricated steel strucutre/building/ warehouse:

Light steel structure project includes three process:design, producing and construction. It main

has three systems: main steel structure system, secondary steel structure system and envelope system...

2. The following the detailed spefication of the prefabricated steel structure/building/warehouse:

Main steel structure
NO	Item	Specification	Remarks
1	Column	H:HN200-550100-2005-10*8-16	Painted Q235 or Q345
2	Roofing beam	HN55020010*16	Painted Q235 or Q345
3	Crane beam	5Tons-15 TONS	Q235
4	Foundation bolt	M24-M45	0.5M-1.3M
5	High strengh bolt	10.9S
Secondary steel structure
1	wall purlin	C160602.5	Painted Q235 or Q345
2	roofing purlin	C200703	Painted Q235 or Q345
3	roofing beam support	L100636	Painted Q235 or Q345
4	column support	L100636	Painted Q235 or Q345
5	bracing	8mm-15mm round steel	Painted
6	stay tube	38mm*1.5mm-3mm round tube	Painted
Envelope system
1	Door	4m5m or 1.8m 2.1m	Engine rolling door
2	window	0.8m *2m	plastic steel swing window
3	wall panel	950mm*50-100mm	white grey 0.4mm eps or rockwool
4	roofing panel	960mm*50-100mm	white grey 0.4mm eps or rockwool
5	Ridge	333mm	0.5mm prepainted steel
6	Accessory	self-tapping scew,rivet, side and front closure,gutter,skylight window

3. For the prefabricated steel structure/factory/building/warehouse,we need to know the following information to design it for you:

No	Item	Specification
1	Dimension	1.Total width: 2.Total length: 3. Building area 4.side wall height 5.Span 6.Column spacing 7.roofing pitch 8. Surface treatment 9. usage of the builidng
2	Design Index	1.Design live load(KN/M2) on floor live load(KN/M2) on wall 3. Max crane load(Ton) 4. Max crane lift height (M) 5.Max window Load (KN/M2) 6. Max Rain Load (KN/M2) 7.Max snow load (KN/M2) 8. Max earthque Load (KN/M2)
3	Enclosing system	1.Exterior wall-material and thickness 2. roofing material and thickness 3.partition wall -material and thickness
4	Window	1.style: swing,sliding, or rolling 2. manual or engine 3. Size 4. quantity 5. position
5	Door	1.style: swing, sliding or rolling 2. manual or enging3. size 4. quantity 5. position
6	Others	1.drainage system 2.ventilation 3.skylight
