Line of Welding for Production of a Masonry Grid
US$ 1,000 - 35,000
/ Set
1 Set(Min. Order)
- Tianjin port
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Hebei, China | |
| Brand Name | YHT | Model Number | YHT-GWC | |
| Usage | Weld Meshes | Voltage | 440/380V(three Phase Supply) | |
| Current | Alternating Current | Rated Duty Cycle | 50% | |
| Rated Capacity | 125KVA*9 | Dimensions | 20000(L)*3150(W)*3000(H)mm | |
| Weight | 3.5T | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Description
Main parameters-- Automatic Mesh Welding Machine/fence Mesh welded Machine
type 1
| Wire diameter | 2~6mm | Line wire form | pre-cut wire or automatic |
| Weft wire distance | Mini 25mm | Weft wire form | pre-cut wire |
| Line wire distance | 50~300mm | Rated voltage | 380V 50Hz |
| Welding net width | 2500mm | Rated power | 6*125KVA |
| Welding speed | 60times/min | Overall dimention | 24*6.0*2.65m |
| Line wire No. | 51 | Wire net length | 6000mm |
Type 2
| Wire diameter | 5~12mm | Line wire form | pre-cut wire |
| Weft wire distance | 100mm | Weft wire form | pre-cut wire |
| Line wire distance | 100~300mm | Rated voltage | 380V 50Hz |
| Welding net width | 2500mm | Rated power | 13*125KVA |
| Welding speed | 50times/min | Overall dimention | 24*6.0*2.65m |
| Line wire No. | 24 | Wire net length | 6000mm |
Type 3
small type welded wire mesh machine
Wire diameter | 0.4-0.65mm | 0.65-1.2/1.8mm | 1.0-2.2mm/2.5mm |
Aperture/pitch | 1/4”-1/2” | 1/2”-4” | 1”-4” |
Mesh width | 3 feet, 4feet | 4 feet, 5 feet | 4 feet, 5 feet, 6 feet, 7feet |
Motor | 2.2kw | 2.2kw | 2.2kw;4.0kw |
Welding speed | Max.75 rows/min | Max.120 rows/min | Max.80 rows/min |
Measurement | 2.3*1.3*1.4m | 2.5/2.9*1.3*1.4m | 2.5/2.9*1.3*1.4m |
Transformers | 50kva*3 | 60kva*4;60kva*5 | 60kva*4/5/6/7
|
Packaging & Shipping
Contacts
FAQ
Our Services
Gurantee
We are the number of trade assurance, we have USD36,000 to 100% refund of the Trade Assurance Amount for orders not meeting agreed delivery and quality terms contained in the contract.
