DFFILTRI Stainless Steels Hydraulic Oil filter XNJ Series Magnetic Suction Filter

DFFILTRI Stainless Steels Hydraulic Oil filter XNJ Series Magnetic Suction Filter

1. Product introduction

XNJ series tank mounted suction filters can be installed on the suction line of hydraulic system, which have these  characteristics:

simple structure, convenient installation, easy to clean and replace filter element.

2. Product characteristics

Filter basic construction

XNJ series filters  consist of  flange plate and filter element etc., flange plate and filter element are connected with connecting rod,

the structure design includes bypass valve and clogging indicator of filter element, so as to consist of  the normal operation of the pump.

2.1 Housing

Flange plate: Carbon structural steel plate

2.2 Seals

Perbunan (= NBR); Viton (= FPM) (Customizable)

2.3 Filter element

Filter medium material

High strength carbon steel skeleton

2.4 Optional accessories

ZKF- II Clogging indicator;  ZS-V Clogging indicator

2.5  Type of connection

Flanged connection

2.6 Symbols

3.Type selectoin and technical data

3.1 Order example

3.2Technical data

4. Mounting Size
