SL045019PP SL045020PP Full Complement Cylindrical Roller Thrust Bearing
- Shanghai ; Ningbo for cylindrical roller thrust bearing
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Full Complement Doule Row Cylindrical Roller Bearing Manufacturers SL045012PP
-
Double Row Cylindrical Roller Bearing SL Bearing Manufacturer SL04150PP SL04160PP
-
SL185020 SL185022 Full Complement Cylindrical Roller Thrust Bearing
-
SL185009 SL185010 Double Row Cylindrical Roller Bearing SL18 Bearing Manufacturer
-
SL Full Complement Double Row Cylindrical Roller Bearing SL185011 SL185012 SL185013
-
SL18 2209 Full Cylindrical Roller Bearing for Gearbox , Reducers and Other Machines
Product Details
| Brand Name | SUMA of cylindrical roller thrust bearing | Bore Size | 20, 200 | |
| Outside Diameter | 42, 270 | Model Number | sl04 cylindrical roller thrust bearing | |
| Precision Rating | P6 | Seals Type | Double Sealed | |
| Number of Row | Double Row | Place of Origin | Jiangsu, China |
Product Description
SL045019PP SL045020PP Full Complement Cylindrical Roller Thrust Bearing
Features of cylindrical roller thrust bearing
SPECIFICATIONS | |
Product name | SL04 Cylindrical roller bearing |
Model | SL045019PP |
Precision | P6 |
Thickness | 67mm |
Inner diameter | 95mm |
Outer diameter | 165mm |
Weight | 3.88kg |
Structure | double row, semi locating, full complement |
Application | Agricultural machinery, electric motorcycle, generator |
Package | Wooden box, pulley, etc |
Payment terms | TT. L/C, D/A,D/P,Western Union,Paypal |
Delivery time | 2-4 days for the sample, 7 days for big order |
Catalogue of cylindrical roller bearing axial load for your choice
| Full complement cylindrical roller bearing with snap ring grooves | ||||||||
| Designation | Designation | MASS | Dimensions | basic load ratings | ||||
| Model | REF | KG | d(mm) | D(mm) | B(mm) | C(mm) | DYN.(KN) | STAT.(KN) |
| SL045004PP | NNF5004 ADA 2LSV | 0.2 | 20 | 42 | 30 | 29 | 40.5 | 49 |
| SL045005PP | NNF5005 ADA 2LSV | 0.24 | 25 | 47 | 30 | 29 | 44.5 | 58 |
| SL045006PP | NNF5006 ADA 2LSV | 0.37 | 30 | 55 | 34 | 33 | 50 | 67 |
| SL045007PP | NNF5007 ADA 2LSV | 0.48 | 35 | 62 | 36 | 35 | 63 | 88 |
| SL045008PP | NNF5008 ADA 2LSV | 0.56 | 40 | 68 | 38 | 37 | 76 | 103 |
| SL045009PP | NNF5009 ADA 2LSV | 0.7 | 45 | 75 | 40 | 39 | 92 | 130 |
| SL045010PP | NNF5010 ADA 2LSV | 0.76 | 50 | 80 | 40 | 39 | 97 | 142 |
| SL045011PP | NNF5011 ADA 2LSV | 1.18 | 55 | 90 | 46 | 45 | 115 | 175 |
| SL045012PP | NNF5012 ADA 2LSV | 1.26 | 60 | 95 | 46 | 45 | 120 | 189 |
| SL045013PP | NNF5013 ADA 2LSV | 1.33 | 65 | 100 | 46 | 45 | 125 | 203 |
| SL045014PP | NNF5014 ADA 2LSV | 1.87 | 70 | 110 | 54 | 53 | 168 | 265 |
| SL045015PP | NNF5015 ADA 2LSV | 1.96 | 75 | 115 | 54 | 53 | 194 | 300 |
| SL045016PP | NNF5016 ADA 2LSV | 2.71 | 80 | 125 | 60 | 59 | 203 | 325 |
| SL045017PP | NNF5017 ADA 2LSV | 2.83 | 85 | 130 | 60 | 59 | 211 | 350 |
| SL045018PP | NNF5018 ADA 2LSV | 3.71 | 90 | 140 | 67 | 66 | 305 | 510 |
| SL045019PP | NNF5019 ADA 2LSV | 3.88 | 95 | 145 | 67 | 66 | 315 | 530 |
| SL045020PP | NNF5020 ADA 2LSV | 3.91 | 100 | 150 | 67 | 66 | 330 | 550 |
| SL045022PP | NNF5022 ADA 2LSV | 6.57 | 110 | 170 | 80 | 79 | 395 | 680 |
| SL045024PP | NNF5024 ADA 2LSV | 7.04 | 120 | 180 | 80 | 79 | 410 | 740 |
| SL045026PP | NNF5026 ADA 2LSV | 10.5 | 130 | 200 | 95 | 94 | 540 | 960 |
| SL045028PP | NNF5028 ADA 2LSV | 11.1 | 140 | 210 | 95 | 94 | 610 | 1100 |
| SL045030PP | NNF5030-ADA-2LSV | 13.3 | 150 | 225 | 100 | 99 | 710 | 1260 |
| SL045032PP | NNF5032-ADA-2LSV | 16.6 | 160 | 240 | 109 | 108 | 740 | 1360 |
| SL045034PP | NNF5034-ADA-2LSV | 22.6 | 170 | 260 | 122 | 121 | 960 | 1750 |
| SL045036PP | NNF5036-ADA-2LSV | 30.1 | 180 | 280 | 136 | 135 | 1140 | 2130 |
| SL045038PP | NNF5038-ADA-2LSV | 31.5 | 190 | 290 | 136 | 135 | 1160 | 2210 |
| SL045040PP | NNF5040-ADA-2LSV | 40.8 | 200 | 310 | 150 | 149 | 1350 | 2600 |
| SL04130PP | 319426 DA-2LS | 7.5 | 130 | 190 | 80 | 79 | 430 | 790 |
| SL04140PP | 319428 DA-2LS | 8 | 140 | 200 | 80 | 79 | 445 | 840 |
| SL04150PP | 319430 DA-2LS | 8.4 | 150 | 210 | 80 | 79 | 465 | 920 |
| SL04160PP | 319432 DA-2LS | 8.8 | 160 | 220 | 80 | 79 | 480 | 970 |
| SL04170PP | 319434 DA-2LS | 9.3 | 170 | 230 | 80 | 79 | 490 | 1030 |
| SL04180PP | 319436 DA-2LS | 9.8 | 180 | 240 | 80 | 79 | 500 | 1080 |
| SL04190PP | 319438 DA-2LS | 12.7 | 190 | 260 | 80 | 79 | 520 | 1130 |
| SL04200PP | 319440 DA-2LS | 13.2 | 200 | 270 | 80 | 79 | 540 | 1210 |
Performance Characteristic of cylindrical roller bearing supplier
Cylindrical roller bearings with snap ring grooves are full complement, double row units comprising solid outer and inner rings with ribs,rib-guided cylindrical rollers and sealing rings. The outer rings have grooves for retaining rings. The inner rings 1mm wider than the outer rings and held together by a rolled-in steel strip. The bearings are available as a light series SL04..-PP and in the dimension series 50 as sl0450..-PP.
Sealing&lubricant Sealing rings on both sides protect the running system against contamination and moisture. The cylindrical roller bearings are greased with a lithium complex soap grease and can be relubricated via the outer and inner ring.
Changzhou Suma Precision Machinery Co., Ltd(Changzhou Tianniu Clutch Factory)is a manufacturer specialized in Producing Various cam clutch, one way bearing, one way clutch, backstop clutch, overrunning clutch and other bearings with high technology.
We are following "Best Quality, Best Price, Fast Delivery, Best Serves" to make all of our old and new customers satisfied.
Pre-sale service:
We will delivery the goods in 10 days after your order is confirmed.
After sale service:
Our factory provide technical assistance to support every doubt during usage and maintenance.
Q: How do you pack the sl04 cylindrical roller thrust bearing?
A: Usually sl04 cylindrical roller thrust bearing are packed in the wooden box. It can be done as your specfic demands.
Q: Can i get the samples of sl04 cylindrical roller thrust bearing from you?
A: It is highly encouraged to ask for the samples for quality check.
Q: Can you promise to deliver sl04 cylindrical roller thrust bearing in time?
A: Credit always ranks the top on the list. We will absolutely deliver the goods in 10 days after your order is confirmed.
Any needs, pls feel free to contact me at any time !
