Keyless Locking Assembly RLK 250 Clamping Elements
- Shanghai; Ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
RLK 133 Short Axial Width Clamping Sets Lock-alx
-
Easy to Release Bulging Joining Sleeve RLK 200
-
Expansion Bush RLK 132 Locking Elements With Short Axial Width
-
Locking Parts RLK 130 Clamping Sheath With High Torque
-
No Axial Displacement Expansion Sleeve RLK 131 Locking Device
-
Radial Flat Height Taper Lock Hub and Adapter RLK 110K
Product Details
| Structure | Disc | Flexible or Rigid | Flexible | |
| Standard or Nonstandard | Standard | Material | Steel | |
| Brand Name | Suma | Place of Origin | Jiangsu, China | |
| Model Number | RLK 250 |
Product Description
| Keyless Locking Assembly RLK 250 Clamping Elements | ||
| Details | ||
| Model | RLK250 | |
| Material | steel | |
| Type | cone clamping element | |
| Inner Diameter | 15mm | |
| Outer Diameter | 25mm | |
| Weight | 0.05kg | |
| Width | 16.5mm | |
| Transmissible torque | 28Nm | |
| axial force | 3.7kN | |
Features
1.Centres the hub to the shaft
2. Radial flat height is particularly suitable for small hub outer diameters
3.Quick assembly by central groove nut
4.Easy to release
5.For shaft diameters between 15 mm and 70 mm
Specifications
Changzhou Suma Precision Machinery Co., Ltd is a manufacturer specialized in Producing Various cam clutch, one way bearing, one way clutch, backstop clutch, overrunning clutch and needle roller bearing with high technology
Q: Why do we choose your company?
A: We always insist quality firstl. We have our bearing factory, therefore we have advantage in quality control and price.
Q:What is the delivery time?
A: Most of the bearing we have stock. For small quantity, we will arrange delivery within 3 days.
Q: What is your payment term?
A: Our payment term include L/C, T/T, Western Union, Paypal etc.
Q: Can you send bearing samples first?
A: Yes, we can send bearing samples to check quality first.
