WH-Q520 Gasoline Engine Concree Cutter
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | W&H | Model Number | WH-Q520 | |
| Cutting Depth | 20cm | Diameter of Blade | 35-50cm | |
| Power(W) | 9.0/13.0/13.5 | Weight | 163/148kg | |
| Dimension(L*W*H) | 121.5*61.5*98cm | Certification | CE,SGS,ISO | |
| Power Source | Gasoline,Diesel,Honda |
Product Description
Specifications
WH-Q520 gasoline engine concree cutter1.with CE
2. Concrete or asphalt cutting.
3.Cutting Depth:20cm
gasoline engine concree cutter WH-Q520
gasoline engine concree cutter Features:
1. Its driving way adopts semi-automatic type, which is realized by worm & gear shaft transmission and manual rotation and pushing, this type of transmission way will increase the cutting work stability and make the worker to use this machine more easy and comfortable.
2. It equips 4-stroke engine, which has low voice, small fuel exhaust and economical working cost.
3. This machine has accurate cutting capability and high working efficiency.
4. The cutting disc tool cover is easy for assembly, which is good for the cutting disc tool replacement.
5.This machine can be used for different kinds of concrete and asphalt road floor and ground extending seam.
gasoline engine concree cutter Specification:
Model | WH-Q520D | WH-Q520P | WH-Q520S | WH-Q520H |
Engine type | Diesel, KM186F | Chinese Petrol Engine | BS420 | HONDA GX390 |
Power (hp) | 9.0 | 13.0 | 13.5 | 13.0 |
Weight kg | 163 | 148 | 148 | 148 |
Max. cutting Depth cm | 20 | |||
Blade Size cm | 35-50 | |||
Water tank Capacity L | 46 | |||
Depth Adjustment | Handle Rotation | |||
Driving | Manual Push/Handle Rotation Push | |||
The sound pressure level measured(LpA) | 104Db(A) | |||
The guaranteed sound power level(LwA) | 106Db(A) | |||
Working size(L*W*H)cm | 121.5*61.5*98 | |||
FAQ
♥ Q: What is your MOQ of this item?
A: 1 sets
♥ Q: Is it all right to make customer’s own brand name?
A: Sure, we can be your OEM manufacturer with your authorization of brand.
♥ Q: What are your payment terms?
A: T/T 30% deposit,70% balance against the B/L copy or L/C at sight.
♥ Q: How long is your warranty?
A: Guarantee for one year from ex-factory date.
♥ Q:What is the delievery time?
A: 15-30 days after receiving your deposit.
COMPANY AND PRODUCTION LINE
PACKING AND SHIPPING
EXHIBITION SHOW
gasoline engine concree cutter Certificates:
