Light Weight AAC Brick Equipment Land Requirement

Shandong Hongfa as the top manufacturer for aerated autoclaved concrete block making machine (AAC) , concrete bricks&blocks making machine with over 20 years experience has four branches in China , We win customers at home and abroad bystrong quality and unbeatable service with competitive price , we have exported our products to over 120 countries .

Thanks for your attention to us .

Light Weight AAC brick equipment land requirement

1.AAC light weight  brick equipment , Autoclaved Aerated concrete block machine introduction

    Areated concrete brick (light brick ) is the light and porous buidling material. It has light weight keeping temperature cant burn and other advantages.it can be made into many kinds of bricks(for example:600×200×100,80×80×180,240×115×53,600×200×125),they could be used industry building and common building.they are more and more popular in the world.in the future,they will replace the Clay brick completely.

 2.AAC light weight brick equipment  , Autoclaved Areated concrete block machine common conception

     Common concrete density is usually 1600-2400kg/m3,but Areated concrete are 500kg/m3,600kg/m3,700kg/m3.It has not the big grain,main use silicon material (for example:coal ash,sand,stone dust and others ),through making the material small for example sand,they can be used directly if has enough degree of small (for example coal ash.Mixing  calcium material lime cement water to a special slop,then add the aluminum dust and the additive.Make the aluminum dust and the special slop have a Chemical reflect.then produce Hydrogen to make the concrete slop to expanding or swell,foam.Next,put them into the curing room to concreting cutting steaming curing,last,there will bacome the light brick,the porous rate is 70-80%.

3. AAC light weight brick equipment  , Autoclaved Areated concrete block machine Advantages

     light weight

     Areated concrete density is usually 400-700kg/m3,(according the market in produce ),same as 1/3 of clay brick and  1/5 common concrete.So use the Light brick can reduce the weight of the build more,and also reduce the  beam of roof and pillar press best.then you can see,it can save the material and cost,it also fighting shaking.

keeping temperature

     It has many  porous,the delivery hearting coefficient is 0.9-0.22W/(mk),the same as  1/4 or 1/5 of clay brick,so it is best  materials now in the world. Also many kinds raw material,have lowest wasteMain Material:coal ash sand waste mine material coal stone,stone dust and other silicon materials.

General specification of light weight AAC brick equipment, products ( mm )

Size deviation of autoclave aerated concrete block

Aera and labour need :

Needs 24-36labour for whole line two shifts , and the land area will be according to different capacity from 5600M2-10,000M3.

Service:

We can give one year warranty time for free service , in the period , we can send our engineer to customers place for installaion and training . For any help in the machine whole using life , you can feel free to contact with our after sale deparment for 24 hours . We have set up many sale offices and after-sale offices around the world .

1.Delivery time:within 30 days after receipt of the deposit

2.payment:30% advance payment by T/T, the balance payment by T/T or L/C.

3.Warranty: 1 year.

4.Spare parts: 1 set of the spare parts and 1set of the tools.

5.We will supply the design layout; design the factory layout for you . make the foundation drawings

6.we will dispatch the engineer to your side for the installing machine, training your workers. and the buyer only pay for the airtickets, the foods and the hotel for our engineer .

Instructions of AAC light weight brick equipment from--Hongfa

Products programme

1,Technological Standard

The technological standard of this project is superior products according to the Chinese national standards. The equipments are made according to Chinese standard and criterion.

This project provides the mature tilting technology in China.

2,Capacity

The product is AAC blocks with the capacity of 30,000m3- 300,000m3/year

3. Product specification

The products reach the block requirements of grade 04~07 of GB11968-2006.

Ball MILL can treat the sand and lime raw material

Slurry Tank

Pouring Mixer

cutting machine for  cutting the size of AAC blocks as your size

autoclave for steaming the blocks

If you are interested in ,pls feel free to contact Linda at +86-15264934636 or add my skype:linda112637
