QT10-15 Large Concrete Block Making Machine / Hydroform Brick Machinery in China / Concrete Block Making Machine Factory
- QINGDAO
- T/T
You May Like
-
Fly Ash Hollow and Solid Bricks Forming Machinery (HONGA Brand)
-
QTF3-20 Prefessional Color Pavement Brick Making Machinery / Colour Paving Bricks Forming Machine / Paver Machine Factory
-
QT4-20C Cement Block Making Machine With Color Feeding Syetem
-
FLy Ash AAC Production Line With Germany Standard (automatic System Control)
-
QT6-15C Cellular Concrete Blocks Making Machines Automatic Cement Blocks Making Machinery
-
QT4-15D Multi-functional Concrete Fly Ash Color Face Bricks Blocks Making Machinery Cement Hollow Block Brick Making Machines
Product Details
| Condition | New | Type | Hollow Block Making Machine | |
| Brick Raw Material | Concrete | Processing | Brick Production Line | |
| Method | Hydraulic Pressure | Automatic | Yes | |
| Capacity | 1440~1800pcs/hour | Place of Origin | Shandong, China | |
| Brand Name | hongfa | Model Number | QT10-15 | |
| Voltage | 220V 380V | Power | 44kw | |
| Dimension(L*W*H) | 9350*2320*2950mm | Certification | ISO CE | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1,ISO 9001-2000 CE SGS 2,hydraulic form ,3automatic control by intelligent control 4,produce various of blocks 5,large capacityQT10-15 Large concrete block making machine / hydroform brick machinery in China / concrete block making machine factory
------BY SHNDONG HONGFA
Technical parameter name | Technical parameter value | |||
Main block machine | L x W x H: 3090x2900(When loading, the two side motors of machine is removed, width 1900mm )x2790mm | |||
Rated pressure of hydraulic system | 20 Mpa | |||
Main vibration form | Platform vibration | |||
Vibration frequency | 2800 - 4500r/min | |||
Vibration acceleration | 15 – 20 g | |||
Exciting force | 695 KN | |||
Fixed brick hight | 50 – 200 mm | |||
Pallet size | 950×900×30 mm | |||
Molding cycle | 15 - 25s, If add color time is 20-25s | |||
Feeding device volume | Storage hopper volume: 0.5m3 | |||
Total power | Block making machine 109.85KW | Automatic block making machine 138.35KW | ||
Total weight | About 11000kg | |||
QT10-15 Large concrete block making machine / hydroform brick machinery in China / concrete block making machine factory
Brief intruduction :
Particular storage and discription material system insure the feeding accuracy and avoiding the effect of exterior material. So the products have high density.
Adopting synchronization vibration insures the products making average. The frequency can change according to different technics. Low frequency in feeding material, high frequency vibration makes the different material to have a optimal vibration way.
The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault. Combine with long-istance controlling system, it can achieve scrutiny, controlling, diagnosis.
Control system:
PLC intelligent control. Man-machine interface, control system equipped with complete logic control, production program, malfunction diagnosis system and remote control function. So it doesn’t need a professional person but only need a simple trainning to the operator.
Product scope:
It produces various bricks/blocks including color-face bricks (layered material feeding),through-body tiles,lock linkage blocks, road curb bricks, hydraulic blocks,hollow blocks, perforated bricks, and standard bricks etc.
Main Technical Specifications
Productivity of QT10-15 block making machine
QT10-15 Large concrete block making machine / hydroform brick machinery in China / concrete block making machine factory
QT10-15 Large concrete block making machine / hydroform brick machinery in China / concrete block making machine factory
QT10-15 Large concrete block making machine / hydroform brick machinery in China / concrete block making machine factory
please feel free to tell me if you need more information and any help .it will be our pleasure to be of service to you .
Sale manager : Amy Liu Skype: donghaowen66 MB: 0086 13969983506
