China YIJI brand plate conveyor

plate conveyor Specifications

1. Long time of warranty.

2. Full-closed , wear resistance structure.
3. Horizontal & whole  inclined transport of bulk material.

4. ISO 2001,SEW.

  China YIJI brand plate conveyor

plate conveyor Operating Principles

 When trough conveyor  is conveying  materials, the pressure which comes from the chains in conveying direction of materials and the weight function of materials themselves cause the internal friction.This friction assures the stable condition between material layers, and it can overcome the external frictional  which caused by moving materials in the trough,then make the materials to form a continuous whole  flow to be transported.

plate conveyor special components

1. Scraper chain: alloy steel wear resistance forged links with carburizing heat treatment.

2. Head section: The head wheel is made of wheel hubs and head gear plate,head gear plate is made of alloy steel with quench heat treatment and has strong wear resistance.

3.Middle section: The rectangular closed case with upper and lower wear rail guides inside, the material is 65Mn or 60Si2Mn with heat treatment;the plate thickness of bottom and side plate is over 10mm, it can be customized.

4.Tail section: It has tension devices both sides to adjust the length of chains, to avoid the accident due to chain elongation .

plate conveyor site pictures

plate conveyor  technical Parameters

plate conveyor Packaging and shipping

1. Export packing.(Wooden case, carbon cast and pallet).

2. Container (as customer requirements)

3. It is suitable for long distance ocean transportation.

Our service

I.  Engineers abailable to service machinery overseas.

2. Provide installation guide, equipment manuals,  operation and repair training.

3. Provide random spare parts.

Company information

 Warm tips :

Most of conveyors are not standard products because of the different material, different capacity, different conveying distance and other different requirements, lead to different conveyor width and motor power.

So,we need you send us specific technical datas and requirements, then we provide you the quotation and detailed information. Please refer to the following technical parameters :

1. What 's the material will be conveyed?

Such as the material name, the size,temperature,density,moisture content,etc..

2.What's the conveying distance between the inlet and outlet?

Such as the conveying length is 48 m.

3.What's the conveying capacity do you want?

Such as the required conveying capacity is30 t/h.
