Jaw Crusher PE400x600 PEX250x1200
USD $2,000 - $86,000
/ Set
1 Set(Min.Order)
- 90 Set / Sets per Month
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Jaw Crusher | |
| Capacity(t/h) | 5-500 | Place of Origin | Henan, China | |
| Brand Name | Yufeng | Model Number | PE |
Product Description
Zhengzhou Yufeng Heavy Machinery Co., Ltd has been one of the largest mining machinery manufacturers in China. It mainly deal with Crushing and screening equipments, Mineral processing equipments, Artificial sand and stone making equipments and AAC equipments,dryer and rotary kiln , Lime and Cement production equipment and other equipments.
The Jaw Crusher is widely used in mining, building materials, chemical industry, metallurgy and so on. The Jaw Crusher is suitable for primary and secondary crushing all kinds of minerals and rocks with compressive strength less than 320 MPa.
Working Principle Of Jaw Crusher:
The strip and strip pulley are driven by a motor, and the movable jaw moves up and down via eccentric shaft. The angle between fixed jaw and movable jaw becomes smaller when the movable jaw runs down, then the materials are crushed into pieces. It will become bigger when the movable jaw runs up. The movable jaw board leaves the fixed jaw board under the action of pole and spring , then the end products come out from the crushing cavity.
Features Of The Jaw Crusher:
1. Simple structure, easy maintenance;
2. High crushing ratio, even output granularity;
3. High reliability, low investment;
4. Low noise, less dust.
Type | Technical performance | Motor power (kw ) | Overall dimensions (L¡ÁW¡ÁH ) (mm) | Weight (kg) | |||
Max feed-in size (mm) | Adjustment scope (mm) | Capacity (m3 /h ) | Rotary speed of main shaft (r/min ) | ||||
PEF150x250 | 125 | 10-40 | 1-3 | 285 | 7.5 | 922x745x933 | 700 |
PEF200x300 | 165 | 20-70 | 2-8 | 265 | 11 | 1056x1100x1120 | 800 |
PEF250x400 | 210 | 20-80 | 5-20 | 310 | 18.5 | 1108x1142x1392 | 3000 |
PEF400x600 | 340 | 40-90 | 10-40 | 275 | 30 | 1700x1732x1392 | 7200 |
PEF350x750 | 290 | 30-55 | 20-50 | 300 | 37 | 1900x1806x1808 | 8900 |
PEF500x750 | 425 | 50-100 | 34-68 | 275 | 55 | 2050x1860x2145 | 11320 |
PEF600x900 | 480 | 75-200 | 40-120 | 255 | 75 | 2792x2168x2250 | 17600 |
PEF750x1060 | 630 | 80-200 | 80-160 | 250 | 90 | 4180x2560x3070 | 30530 |
PEF900x1200 | 750 | 100-200 | 110-200 | 250 | 110 | 5200x2900x3500 | 50000 |
PEF1200x1500 | 1020 | 150-300 | 220-400 | 180 | 160 | 4200x3300x3500 | 106000 |
PEX150x750 | 125 | 10-40 | 5-15 | 300 | 15 | 1220x1480x1180 | 3600 |
PEX250x1000 | 210 | 15-55 | 10-32 | 300 | 37 | 1580x1992x1380 | 7350 |
PEX250x1200 | 210 | 15-60 | 12-38 | 300 | 37 | 1530x2192x1380 | 8700 |
PEX300x1300 | 250 | 20-90 | 16-65 | 300 | 55 | 1930x2400x1747 | 11600 |
....
