PPCS96 Series Air Tank Pulse Bag Dust Filter
US$ 32,258 - 322,580
/ Set
1 Set(Min. Order)
- Shanghai Tianjin
- T/T
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | Huanqiu heavy | |
| Model Number | dust filter |
Product Description
Specifications
Dust Filter1.Direct manufacturer.
2.Competitive price.
3.60 Years' Experiences
4.various models suitable for your needs
Description of Air Tank Pulse Bag Dust Filter
This air tank pulse bag dust filter is able to collect dust in different tanks, thus avoiding the secondary dust problem. It can deal with not only dusty gases with general dust concentration, but also dusty gases with 1000g/Nm3.
Technical Parameters of PPCS96 Series Air Tank Pulse Bag Dust Filter:
| Model Technological parameters | PPCS96-4 | PPCS96-5 | PPCS 96-6 | PPCS 96-7 | PPCS 96-8 | PPCS 96-9 | PPCS 96-2×5 | PPCS 96-2×6 | PPCS 96-2×7 | PPCS 96-2×8 | PPCS 96-2×9 | PPCS 96-2×10 | ||
| Air processing volume (m3/h) | 26800 | 33400 | 40100 | 46800 | 53510 | 60100 | 66900 | 80700 | 94100 | 107600 | 121000 | 134500 | ||
| Air filtering speed (m/min) | 1.2-2.0(The dust filtering speed varies depending on different dust collection points, and specific velocity needs referring to form1. ) | |||||||||||||
| Total filtering area (m2) | 372 | 465 | 557 | 650 | 744 | 836 | 929 | 1121 | 1308 | 1494 | 1681 | 1868 | ||
| Net filtering area(m2) | 279 | 372 | 465 | 557 | 657 | 744 | 836 | 1028 | 1215 | 1401 | 1588 | 1775 | ||
| Amount of dust collecting chamber | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 12 | 14 | 16 | 18 | 20 | ||
| Amount of filtering bags | 384 | 480 | 576 | 672 | 768 | 864 | 960 | 1152 | 1344 | 1536 | 1728 | 1920 | ||
| Resistance of dust collecting bag filter(Pa) | 1470-1770 | |||||||||||||
| Dust concentration of inlet air (g/m3 ) | <1300 | |||||||||||||
| Dust concentration of discharged air (g/m3) | <0.1 | |||||||||||||
| pressure bearing capacity of bag filter shell (Pa) | 5000 | |||||||||||||
| compressed air for dust collecting | Pressure (Pa) | (5-7)×105 | ||||||||||||
| Air consumption (m3/min) | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3.0 | 3.4 | 4.2 | 4.8 | 5.4 | 6.0 | ||
| Pulse valve (with solenoid valve) | Amount | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 12 | 14 | 16 | 18 | 20 | |
| Specification (inch) | 2 1/2” | |||||||||||||
| Lift valve (with air cylinder) | Amount | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 12 | 14 | 16 | 18 | 20 | |
| Specification (mm) | Diameter of lift valve: 725; diameter of air cylinder: 100 | |||||||||||||
| Rigid impeller feeder | Feed opening: 400×400mm, rotating speed:22.5r/min, power of speed reducer:1.5kw, output: 40m3/h | Feed opening: 350×350mm, rotating speed: 24.63r/min, power of speed reducer: 1.5kw, output: 30m3/h, 2 sets | ||||||||||||
| Screw conveyer | Specification | Diameter: 400, output:38m3/h | Diameter: 300, 2sets; output of each set: 21m3/h | |||||||||||
| Speed reducer | Model: XWD5.5-7-1/59, power: 5. 5kw | Model: XWD2.2-5-1/43,power: 2.2kw | ||||||||||||
| Air slide conveyor | When the dust concentration of feeding air is more than 700g/m3, environmental protection equipment, with air slide or large-size screw conveyor, should be utilized. | |||||||||||||
| Controller of dust collecting program | Both of the input and output voltages are 220 V. | |||||||||||||
| Specifications and material of filter bag | Diameter×length: 130×2450mm; weight of polyester needle felt: 450g/m2; use area: 120°C | |||||||||||||
| Area of thermal insulating layer (m2) | 110 | 120 | 130 | 140 | 150 | 160 | 175 | 210 | 245 | 280 | 315 | 350 | ||
| Total weight (excluding thermal insulating layer) (kg) | 8710 | 10100 | 12400 | 14100 | 15700 | 17700 | 21000 | 25200 | 29400 | 33600 | 37800 | 42000 | ||
Note: 1. The net filtering area in the above form means the filtering area when the dust collecting work is done by only dust chamber.
