Concrete Mixer JS1000

FOB Price

US$ 22,000 - 26,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shandong, China
Brand Name	Lianchuang	Model Number	JS1000
Motor Power	57KW	Charging Capacity	1600L
Reclaiming capacity	1000L	Working Cycle Period	more than 50/h
Discharge Way	Pneumatic	Outline Dimension	9705X3695X8495
After-sales Service Provided	Engineers available to service machinery overseas

JS1000 concrete mixer is dual horizontal shaft concrete mixer, which can can work independently, also can be

composed the concrete batching plant with PL1600 and other matched equipment., and it can be applicable to

large, medium and small precast concrete products factory and roads, railways, bridges, water conservancy,

civil construction project, and it can mix dry and hard concrete, plastic concrete, light aggregate concrete and all

kind of mortar, it is one kind of high efficiency, widely used construction machinery. It owns reasonable design ,

and its mechanical accessories used industry standard parts, and its maintenance is much convenient.

Main technical parameter

Model		JS1000
Charging Capacity (L)		1600
Reclaiming capacity (L)		1000
Rated production rate m3		50-60
Aggregate Maximum grain diameter	Scree (mm)	80
	Gravel(mm)	60
Stirring vane	Rev(r/min)	27
	QTY	2×8
Main motor power KW		37
Discharging height (m)		3.8
Discharging type		Pneumatic
Total weight(Kg)		11000
Overall dimensions (LXWXH) mm		9500×3800×8605
