80t/h Mobile Asphalt Mixture Plant
- Tianjin Shanghai Qingdao Xiamen Port
 - T/T L/C D/P D/A Credit Card

You May Like
Product Details
| Condition | New | Place of Origin | Fujian, China | |
| Brand Name | Nanqiao | Model Number | QLBY | |
| Voltage | 220V/380V-50Hz | Certification | ISO | |
| Warranty | Installed 15 Months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Mobile Hot Asphalt Drum Mix Plant
High automation
Accurate measuring
High reliability
Simple structure
Stable output
Mobile Asphalt Mixing Plant can produce asphalt mixture,which is a high grade material of road surface. Thus,asphalt is widely used inHighway, High Grade Roads, Municipal Roads, Airports and Ports construction.
The QLBY 60 mobile asphalt mixing plant is independently created by our company in the national initiative to develop a state of the art modular design for asphalt batch plant. With simple, aesthetically appealing structure, the equipment features high modularity in design.
The eco-friendly batch plant is also energy efficient. It is quite reliable, allowing for ease of installation, operation, and transportation. The resulting asphalt concrete has good quality and stable performance, which is widely used for the construction of highway, bridge, and other infrastructure as well as suitable for daily road repair and maintenance.
Features
 1. The combined structure of drum dryer and batcher is mounted onto the movable support, which facilitates their movement.
 2. The asphalt mixing plant comes with twin horizontal shafts that are able to bring the aggregates to a fierce boil, which ensures a thorough mixing.
 3. Hot aggregate is vertically lifted up in the densely arranged hanging buckets. This kind of lifting tool is easy, reliable to use.
 4. For accurate weighing of aggregates, bitumen, and pulverized mineral, the measurement scale is used, which contains a weight sensor for electronic metering.
 5. The movement of power material follows an enclosed, spiral path which guarantees minimum material loss as well as provides safety transfer.
 6. At the cyclone burner, high pressures oil is sprayed out and atomizes quickly. Within the combustion chamber, the material is fed in a spiral manner and ignited automatically by the oil spray, which ensures combustion efficiency. The cylindrical barrel of the burner is separated from the burner head. The barrel cavity can be pushed in and pulled out, which facilitates the change of damaged jamb brick inside the burner head. The whole burner features large heat capacity and great hot strength. It is also cost effective.

Technical Parameters
Model  | QLB-10  | QLB-15  | QLB-20  | QLB-30  | QLB-40  | QLB-60  | QLB-80  | |
Capacity  | 10t/h  | 15t/h  | 20t/h  | 30t/h  | 40t/h  | 60t/h  | 80t/h  | |
Total Power  | Fuel Oil  | 41.5kW  | 54kW  | 63.5kW  | 104.5kW  | 125kW  | 157.5kW  | 200kW  |
  | Fuel Coal  | 57.5kW  | 75kW  | 86.5kW  | 127.5kW  | 169kW  | 205kW  | 276kW  |
Aggregate Batcher  | 2.3m3*3  | 2.3m3*3  | 2.3m3*3  | 5m3*3  | 5m3*3  | 5m3*3  | 5m3*4  | |
Finished Asphalt Storage Bin  | 2t  | 5t  | 5t  | 9t  | 9t  | 9t  | 20t  | |
Asphalt Temperature  | 120-180°C (adjustable)  | |||||||
Fuel Consumption  | Fuel Oil: 5-7.5 kg/t; Fuel Coal: 13-15 kg/t  | |||||||
Optional Components  | Water dust collector, Baghouse dust collector, Control room, Bitumen heating tank  | |||||||
Model  | QLB-10  | |||||||
Capacity  | 10t/h  | |||||||

Our company is a private high-tech enterprise group, mainly engaged in road building and maintenance machinery developing and manufacturing, highway engineering construction and international trade. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
Our company always puts the interests of customers at the first place, take the demand of customers as the source and power of development of the company, and constantly make technology innovation and product technology extension since the establishment. With the cooperation of Zhengzhou University in 2002, the developed intelligent mobile asphalt mixing equipment rapidly occupied the market, and obtained the tile of "Henan High-tech Enterprise"
Adheres to the objective of "concentration, carefulness, high-quality products", and sticks to strict quality management, and has passed the ISO9001:2008 quality management system certification. Our company wins the praise of customers from the "professional, timely, careful" services, and is appraised as "quality, reputation, service AAA enterprise” by our national government.
As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching Poland, Rumania, Russia, Australia, New Zealand, Canada, Panama, Ecuador, Peru, Chile, Algeria, Kenya, South Africa, Zimbabwe, Philippines, Indonesia, Kazakhstan, Mongolia, Egypt, etc.


1. Pre-sale services
Act as a good adviser and assistant of clients; enable them to get rich and generous returns on their investments;
(1) Select equipment model;
(2) Design and manufacture products according to clients' special requirement;
(3) Train technical personnel for clients.
2. Services during the sale
Respect clients; devote ourselves to improving the total value of clients.
(1)Pre-check and accept products ahead of delivery;
(2)help clients to draft solving plans.
3. After-sale services
Provide considerate services to minimize clients' worries.
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4) Examine the equipment regularly;
(5)Take initiative to eliminate the troubles rapidly at site;
(6) Distribute the guarantee fittings door-to-door;
(7)provide perfect service;
(8)Provide technical exchanging;
(9)Provide maintenance for big items.
