3 Pistons/13Mpa High-pressure Grout Injection Pump
- SHANGHAI/ NINGBO PORT
 - T/T Credit Card

You May Like
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Zhejiang, China | Brand Name | Wengong | |
| Model Number | 3 SNS grout injection pump | Power(W) | 18.5kw | |
| Weight | 930kgs | Dimension(L*W*H) | 1800 x 945x705mm | |
| Certification | CE, ISO9001:2008 | Warranty | 6 months | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
High-pressure grout injection pump1.3-pistons in grout pump
2.stable grout to 200m deeply
3.ISO9001:2000, make over 15years
                                                   3SNS  Grout injection pump

3SNS High-pressure grouting pump can be used for both cement and mortar high grouting and spraying.
It is mainly characterized in its high pressure, stable flow, rational structure and convenient operation.
Be mainly used for foundation curtain grouting, slope consolidation grouting, tunnel grouting and related grouting projects, which can be used for geological bore core drilling instead of slurry pump.

Technical parameters
| Model | 3SNS | 3SNS-1 |
| Mortar Output | 76~207 L/min | 83.7~130 L/min |
| Max Working Pressure | 12~4Mpa | 13.4~8.6 Mpa |
| Motor power | 18.5kw | 22kw |
| Diameter of entery pipe | 64mm | 64mm |
| Diameter of exit pipe | 32mm | 32mm |
| Pistons qty | 3pcs | 3pcs |
| Net Weight | 930kg | 930kg |
| Dimension | 1800×945×705mm | 1800×945×705mm |
1. 3SNS grouting pump is widely to grouting of piling in high-rise buliding.
2. 3SNS is only grouting cement slurry and works with ZJ-400 cement mixer which has fast speed about 3min for 400L.

3. 3SNS is packed into Firm fumigation wooden box .
