2015 New-technology Palm Oil Mill Plant

Refining of vegetable oils is essential to ensure removal of gums, waxes, phosphatides and free fatty acid (F. F.A.) from the oil; to impart uniform colour by removal of colouring pigments and to get rid of unpleasant smell from the oil by removal of odiferous matter.

Crude oil can be refined as Second,first and high class cooking oil.It can be heated by thermal oil and Omitted the boiler.

The refinery can be operated easily and intermittent.It has all the functions of Large and medium-sized refinery and widely used.

The unit is integrated in one assembly factory.It has the advantage of convient transportion,small covering area,less operation staff and saving energy.It is no need of special plant and special equipment.It can be set indoor and outdoor.

Refining Method:

 The oil refinery machine can adopts chemical refining and physical refining, and the chemical refining includes batch refining, semi-continuous refining and continuous refining.

Main equipments of oil refinery plant:

1.Neutralization Tank: used for acid refining, alkali refining or washing.

2.Bleaching Tank: used for bleaching oil & removing pigment.

3.Deodorizing Tank: used for removing the odour of oil (made of stainless steel).

4.Conduction Oil Furnace: provide production with heat source, and the temperature can reach 280 °C.

5. Vacuum Pump: provide vacuum degree for bleaching & deodorizing process, which can reach above755mmHg

 6. Air Compressor: weather bleaching earth used in the bleaching process

 7. Filter Press: filtrate the bleaching earth

 8. Steam Generator: produce steam for deodorization and distillation process

9.leaf Filter: filtrate the bleaching earth & impurities.
