Home > Products > Boiler and Pressure Vessel > Electrical heating steam boiler
Electrical heating steam boiler
- china main ports
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Natural Circulation | |
| Usage | Industrial | Structure | Water Tube | |
| Pressure | High Pressure | Style | Vertical | |
| Fuel | Other, electrical | Place of Origin | Henan, China | |
| Brand Name | bidragon | Model Number | LDR | |
| Output | Steam | Dimension(L*W*H) | 800*600*1300mm | |
| Weight | 500kg | Certification | iso9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Model: LDR(3-18)-0.4ZHeating power: 3KW----18KW
Voltage: 220V/380V
Rated operating pressure: 0.4~0.7Mpa
Product name:
vertical steam boiler
Middel type electric steam boiler: Vertical
Model | Steam Output Kg/h | Rated Power KW | Rated Operating Current A | Electric Cable Paramete | Outline Dimension mm | Weight Kg | Steam outlet Valve Dia. DN | Blown Down Valve Dia. DN | Water Inlet Valve Dia. DN |
LDR0.27-0.7 | 270 | 192 | 290 | 3*120+2(Copper Cable) | 1000*1000*1800 | 520 | 40 | 40 | 25 |
LDR0.30-0.7 | 300 | 216 | 328 | 3*150+2(Copper Cable) | 1000*1000*1800 | 520 | 40 | 40 | 25 |
LDR0.34-0.7 | 340 | 240 | 364 | 3*185+2(Copper Cable) | 1000*1000*1800 | 520 | 40 | 40 | 25 |
LDR0.4-0.7 | 400 | 288 | 436 | 3*240+2(Copper Cable) | 1000*1000*1800 | 520 | 40 | 40 | 25 |
LDR0.5-0.7 | 500 | 360 | 545 | Double 3*120+2(Copper Cable) | 1200*1200*2000 | 680 | 40 | 40 | 25 |
LDR0.6-0.7 | 600 | 432 | 655 | Double 3*120+2(Copper Cable) | 1200*1200*2000 | 680 | 40 | 40 | 25 |
Model: LDR(3-18)-0.4Z
Heating power: 3KW----18KW
Voltage: 220V/380V
Rated operating pressure: 0.4~0.7Mpa
Vapor capacity: 3.8~22.8kg/h
Effective water volume: 28L
Power: 380V 50Hz
Heating Power: 20kW --144 kW two standards
Steam Feeding: 30Kg_200Kg/H
Water Supply: According to the standard of water using in the boiler
Designing Pressure: 0.70MPa
Designing Temperature: 170 celsius degree
Contact Us
- Beijing Double Dragon International Industrial & Mining Machinery Co., Ltd.
- Contact nameMacros Zhang Chat Now
- Phone86-372-2190222
- AddressNo. 2-1803, Soubao Business Center, No. 16
