Home > Products > Planatery Mixer > Vertical Powder Mixer Vertical Shaft Concrete Mixer
Vertical Powder Mixer Vertical Shaft Concrete Mixer
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Jianling | Model Number | MP500 | |
| Mixing Power | 18.5 | Charging Capacity | 750L | |
| Reclaiming capacity | 500L | Outline Dimension | 2220 X 2071 X 1880mm | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
vertical powder mixer vertical shaft concrete mixer1. ISO TUV after service
2. Different types, Customized
3. Efficient
vertical powder mixer vertical shaft concrete mixer
Model: MP500
Mixing Power: 18.5kw
Charging Capacity: 750L
Discharging Capacity: 500L
Discharging Weight: 1200kg
Size: 2220 X 2071 X 1880mm
Weight: 2000kg
The hydraulic discharge power: 2.2kw
Planet/Vane: 1/2
Side Scraper: 1
Discharging Scraper: 1
Lifting Hopper Power: 4kw
Lifting Speed: 0.25m/s
Hopper Capacity: 870L/1305kg
The above is Planetary Mixer MP500 technical parameter.
Model | MP500 | MP750 | MP1000 | MP1500 | MP2000 |
Mixing Power | 18.5kw | 30kw | 37kw | 55kw | 75kw |
Discharging Capacity | 500L | 750L | 1000L | 1500L | 2000L |
Charging Capacity | 750L | 1125L | 1500L | 2250L | 3000L |
Discharging Weight | 1200kg | 1800kg | 2400kg | 3600kg | 4800kg |
Size/mm | 2220X2071X1880 | 2581X2336X2195 | 2891X2602X2217 | 3223X2902X2425 | 3625X3230X2630 |
Weight | 2000kg | 3500kg | 6000kg | 7000kg | 8500kg |
The hydraulic discharge power | 2.2kw | 2.2kw | 3kw | 3kw | 4kw |
Planet/Vane | 1/2 | 1/3 | 2/4 | 2/4 | 3/6 |
Side Scraper | 1 | 1 | 1 | 1 | 1 |
Discharging Scraper | 1 | 1 | 1 | 1 | 2 |
Lifting Hopper Power | 4kw | 7.5kw | 11kw | 15kw | 22kw |
Lifting Speed | 0.25m/s | 0.25m/s | 0.25m/s | 0.25m/s | 0.25kw |
Hopper Capacity | 870L/1305kg | 1300L/1950kg | 1740L/2610kg | 2610L/3915kg | 3480L/5220kg |
vertical powder mixer vertical shaft concrete mixer
