Continuous Casting Machine From Sally

Sn.

Name

Main configuration and technical specification

Quantity

Unit

Remark

1

60X60mm crystallizer

CNC processing inside water jacket, outside water jacket;

Copper pipe sealing ring;

Water seam width:4mm;water flow rate:10m/s

Copper pipe material:Cu-P;plating of lining:Cr

Copper pipe length700mm

1

set

Standard table plate

2

First cooling system

Automatically switch on the cooling water when crystallizer in place;

Flow regulating method:manual switch water supply,manual regulating flow;

Configuration:pressure gauge;related pipes,three direct links,brake valve,elbow, etc.

1

set

3

Mould vibration table

Vibration reducer

Ordinary half plate spring vibration table

Bearing,22212

Plate spring,1100X140X14

Basin angle gear reducer,regulating amplitude,power 5.5kw.

1

table

standard

4

Secondary cooling system

Diversion box,valve;spring pressure gauge,three direct links,elbow, etc.

1

Set

5

Secondary cooling arc direction

Low roller water cooling diameter:158mm

Upper water cooling diameter:100mm

1

Set

6

60×60 spray header

Structure type:arc stainless steel square tube

Divided into three sections;two cooling zero segment(crystallizer mouth);two cooling one segment,two cooling two segments.

Nozzle type:5265,water nozzle.

1

Set

7

Tension leveler

Roller,cooling bearing seat;AC variable frequency transmission.

Roller material:alloy forge steel,roll surface welding wear-resisting material. Turbine worm reducer.

1

Table

AC motor

Power 3.0KW, revolving speed:1500r/min

3

Table

Reduction box

1,Cycloid reducer:transmission ratio i=9

2,Turbine worm reducer:transmission ratio i=29

3

Table

Rotating joint

Structure type:built-in.

Tension lever hydraulic cylinder

Cylinder diameter:125mm;Rod diameter:80mm.

1

Unit

Off billet hydraulic cylinder

Cylinder diameter:125mm;Rod diameter:80mm.

1

Unit

8

Dummy bar fitting

Structure type:flexible dummy bar,section size 80×120mm,dummy head material:alloy forge steel

1

Set

9

Roller before cutting

Structure type:free short roll

Roller diameter:φ219mm

Roller length:260mm

1

Set

11

Roller after cutting

Structure type:shunt short roller,concentrate chain transmission

Roller gap :~

Roller diameter :φ219mm

Roller length:260mm

1

Set

12

Billet roller

6m

1

Set

13

Hydraulic pusher

6m

1

Set

14

Main hydraulic system

Motor:7.5KW

1

Set

Automatic 4 valves.

15

Oil pump

Model:CB-31.5-FL18

1

Set

16

Electric system

Tension frequency power:15KW

Oscillation frequency power:7.5KW

1

Set
