Home > Products > Metallurgical Equipment > CNC Horizontal Lathe From Sally
CNC Horizontal Lathe From Sally
- chinese port
- T/T
You May Like
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | CNC | Automatic Grade | Automatic | |
| Max. Swing Diameter | 400mm | Place of Origin | Liaoning, China | |
| Brand Name | Chinese brand | Model Number | CW61125E-(TS) | |
| Voltage | 380V | Power(W) | 22KW | |
| Dimension(L*W*H) | 1900X1210X1600mm | Weight | 2500KG | |
| Certification | ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Ⅰ .Main technical parameter of lathe
Item | Unit | Specification | Remark | |
Max swing over bed | mm | 1000 |
| |
Chuck diameter | mm | 800 |
| |
Max workpiece length | mm | 2000 |
| |
Max rotating diameter of sliding plate | mm | 650 |
| |
Max turning length | mm | 2000 |
| |
Spindle | Diameter of spindle hole | mm | 90 |
|
Number of speeds |
| Nine grades |
| |
Range of speed | r/min | 42 |
| |
Main motor power | kW | 11 |
| |
X/Z axle fast moving | m/min | 6/10 |
| |
X axle stroke | mm | 400 |
| |
Z axle stroke | mm | 2000 |
| |
Tailstock | Sleeve diameter/stroke | mm | 115/450 |
|
Taper hole of tailstock spindle | Mohs | Mohs number 6 |
| |
Height of center(from bed/ground) | mm | 500/1050 |
| |
Max workpiece weight | t | 1 |
| |
Ⅱ . Machine precision
Inspection items | Inspection standard |
Working accuarcy | 0.02 |
Cylindricity of workpiece | 0.03 / 300 |
Flatness of workpiece | 0.025/300 |
Roughness of finished surface | Ra3.2μ
|
Ⅲ . Comapny introduction
AnShan HongMing Metallurgical Machinery Co., Ltd. ,Anshan Yingyi Trading Co., Ltd.Comprehensive group enterprise , is a large company which combines production, operation together. We have our own right for import and export. We have forging,costing and heating treatment workshops with advanced producing equipments, a large number of the engineers and skilled workers, we can design , produce and export to the destination country where designated by clients. If you are interested in moulding equipment and complete plant, we can provide our users’ with a series of service, such as design, manufacturing, installation, debugging and trial production.
