ES /PS /PVC/PAN /PVDF inside out pressure hollow filber uf membrane/8040 inch pvdf hollow filber for industrial water treatment

pvdf hollow filber

  UF membrane has different types such as plate, tubing, hollow fiber and spiral etc.  Meanwhile, hollow fiber membrane is the most stable and advanced type, compared with others, it is smaller in size, larger in area, bigger in flux and not easy to block.  As one of the six hi-technologies in 21st century, the separation technology of UF membrane possesses some distinctive characteristics such as: operated in normal temperature and low pressure, no phase transition and low consumption.

  Standard offer according your application, requirement and budget directly supply,pore sizes in the range of 0.1 to 0.001 micron hollow fiber uf membrane

pvdf hollow filber  ( hollow fiber uf membrane ) features:

 1. The unique design of the flow channel, reducing water resistance

2.  When backwashing the membrane surface water distribution synchronization, more thorough cleaning

3.  Membrane wire fixed partition, the lowest risk of wire-breaking after long run time

4. Hydrophilic modification and improve the stain resistance

5. Continuous three-phase asymmetric structure, and enhanced the intensity of the membrane filaments

6. Reduce the pollution of the hole channel, let backwashing more easier when restoring flux

Advantages of pvdf hollow filber   :

-High Strength

 UF membrane is made of long chain hydrophilic material modified PS with special technology and strict quality control standards, owning excellent anti-explosive and stretching characteristics. The explosive pressure reaches up to 10 bar.

-Higher fulx & stable operation

UF membrane owns a unique pore structure with lower membrane resistance. Flux recovery is 20%-30% higher than similar products, due to its long molecular material.

-Anti-fouling & anti-oxidant

It has an obvious advantage on cleaning and flux recovery, due to the special technology.

Application of pvdf hollow filber  :

-Ground water&mine water

-Surface water

-Boiler feed water

-Sea water desalination pretreatment

-Municipal waste water

-Industrial waste water

-Recirculation waste water

-Textile waste water

-Chemicial waste water

-Pesticide waste water etc.
