Home > Products > Geotextile > 245g PP black nonwoven geotextile for foundation construction

245g PP black nonwoven geotextile for foundation construction

FOB Price

USD $0.17 - $2.69 / Square Meter

6000 Square Meters(Min.Order)

Supply Ability 22 Ton / Tons per Month
Port Qingdao Shanghai Tianjin
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	BPM
Model Number	BPMGT		Geotextile Type	Non-Woven Geotextiles

Product Description

>>Introduction

Stable Fiber Needle Punched Geotextile

The needle-punched non woven geotextile is produced from polyester or polypropylene fiber by different equipment and technology to get different thickness .The main function is filtration ,drainage ,reinforcement .It has good impermeability and resistance to deformation.

Filament polyester geotextile

The filament non-woven geotextile is produced from polyester long fiber forming into net and consolidation with three dimension structure.It's kind of new material in geotechnical and engineering project .Except for its good mechanical properties of tensile strength and puncture resistance ,it also has good drainage ability ,acid and alkali resistance and anti-aging .The wider opening size allows it has good permeability and filtration .

>>Specification

raw material	PET continuous filament fabric /PET staple fiber fabric
color	white/black/grey or as your request
gsm	100g/m2 to 800g/m2
roll size	width(1m to 6m),length(50m to 200m)
process	spun-bonded,needle punched,if required,heat-set is also available
packing	PP woven plastic bags
project	road construction,geomembrane protection,river bank erosion control,etc

>>Features

high elongation
high tensile strength
excellent permeablity
durable CBR puncture resistance and UV stabilized

>>Technical Parameter

No.	Specification(g/m2)	100	150	200	250	300	350	400	450	500	600	700	800	1000	Remark
1	Weight deviation, %	-8	-8	-8	-8	-7	-7	-7	-7	-6	-6	-6	-6	-6
2	Thickness, mm≥	0.9	1.3	1.7	2.1	2.4	2.7	3	3.3	3.6	4.1	4.5	5	5.8
3	Width deviation,%	-0.5
4	Breaking strength, KN/m ≥	2.5	4.5	6.5	8	9.5	11	12.5	14	16	19	22	25	31	MD and CD
5	Breaking elongation,%	25~100													MD and CD
6	CBR bursting strength, KN≥	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7	3.2	3.7	4	5
7	Sieve Size O90 mm	0.07~0.2
8	Vertical permeability	Kx(10-1~10-3 )													K=1.0 ~9.9
8	coefficient, cm/s	Kx(10-1~10-3 )													K=1.0 ~9.9
9	Tear strength, KN≥	0.08	0.12	0.16	0.2	0.24	0.28	0.33	0.38	0.42	0.46	0.53	0.6	0.75	MD and CD

>> Function of geotextiles

1.Separation

The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different

granule pathway from the groundsill or other buildings.
2.Reinforcement
The highway, railway, soil-stone dam, breakwater, airport, backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earthbody stability.
3.Protection
It prevents the bank from being washed out, protects the bank and the

bottom, prevents the water and soil from being washed away

>>Application

All have a wide range of applications and are currently used to advantage in many civil engineering applications including roads,airfields,railroads,embankments,retaining structures,reservoirs,canals,dams,bank protection coastal engineering and reinforce the roadbed.

>>Our Packing

Geomembranes are wrapped double layers woven geotextile,and added two strips at both ends.

Geotextiles are wrapped double layers woven geotextile.

Of course, If you have any requests, we will package products as your request.

All products will be loaded container safely.

>>Our Certificates

We have obtained SASO, SONCAP, BV, ISO and other certificates.

And we also have passed DEKRA, Intertek, CNAS and other tests.

Our quality is reliable.

If you have any other test or certificate, we can do it for you.

**If you have any question ,feel free to contact me .
