Product Details
| Place of Origin | Shandong, China | Brand Name | BPM | |
| Model Number | BPMGCL1009 | Material | geotextile | |
| Specification | BPMGCL1009 |
Product Description
Specifications
bentonite Clay Liners+geotextile and geomembran bentonite geosynthetic clay liner1,one side is geotextile ,one side is weav g
1,GCL (Geosynthetic Clay Liners)+geomembrane are high performance needle punched enbironmental reinforced composites which combine two duiable geotextile outer layers with a uniform core of natural soidum bentonite clay to form a hydraulic barrier.Fibers from the non-woven geotextile are needle punched through the layer of bentonite and incorporated into the other geotextile.
When hydrated under a confining load,the bentonite swells to form a low permeability clay layer with the equbalent hydraulic peojection of several feet of compacted clay.The excellent properties make the products ideal for many projects.
Physical Performance
Testing Item | Testing Methods | Technical Indexes |
Expansion Coefficient | ASTM D 5890 | ≥27ml/2g |
Fluid Loss | ASTM D 5891 | ≤18ml |
Bentonite quality in Unit area | ASTM D 5993 | ≥4.8kg/m2 |
Tension Strength | ASTM D 4632 | ≥400N |
Peeling Strength | ASTM D 4632 | ≥75N |
Indicating flow | ASTM D 5887 | ≤1*10-8m3/m2/sec |
Penetrability | ASTM D 5887 | ≤5*10-9cm/sec |
Tension Strength after Wetting | ASTM D 5321 | ≥24Kpa typical |
