Singflo 12v 40 L/Min Heat Fuel Oil Transfer Dispensing Pump
- FOB China Port
- Credit Card PayPal
You May Like
-
Singflo12v Portable Diesel Fuel Pump Dispenser System/fuel Oil Dispenser
-
Singflo HV-50M 50LPM Diesel Engine Oil Pump for Car
-
Singflo 30LPM 24v dc Oil Filling Pump/heavy Cargo Oil Pump
-
Singflo 5 Gallon Plastic Oil Jugs With Lids
-
Heat Fuel Oil Transfer Dispensing Pump
-
Singflo 12v&24v dc Fuel Transfer Pump With Low Noise and Long Lift for High Tempreture 150C
Product Details
| Place of Origin | Fujian, China | Brand Name | Singflo | |
| Model Number | YTB40-12 | Theory | Centrifugal Pump | |
| Structure | Other, fuel oil transfer 12 dc | Usage | Oil | |
| Power | Other, Electric, 155 Watt | Standard or Nonstandard | Standard | |
| Fuel | Diesel | Pressure | Low Pressure | |
| Application | Other, fuel oil transfer with 220 volt |
package with carton,inside with foam
Product Description
Singflo 12v 40 L/Min Heat fuel oil transfer dispensing pump
The DC oil pump has been tested and passed through a strict performance test for temperature
resistance and antihock with a high quality protection rating of IP55.
Car batteries may be used to power the pump for fast and convenient fuel pumping.
It may be also used with a fueling nozzle and filters for ensuring the flow of clean diesel or kerosene fuel.
This pump is designed for all kinds of machinery, tractor and farm equipment.
Specification:
It is an ideal portable pump for diesel and kerosene etc.
Our oil pump is through the strict aseismatic anti-scar performance tests.
IP standard is IP55, with inner by-pass valve,with excellent quality. It works
With various battery and has the feature of self-priming function.
Pump is only working with diesel oil and oil with similar specs. It's strictly
Prohibited for gasoline and low flash point mediums.
Pump casing and impeller is made of cast iron.
Note: Not suitable for low-ignition fuel (such as gasoline, liquefied petroleum gas, alcohol, etc.) transmission.
Technical Data:
Failture and Resolution:
Trouble | Reasons | Treatments |
No initial oil output | 1.Polarity reversed(+/-) | 1.Correctly attach polarity to power source+/- |
| 2.Leak in suction line | 2.Ensure the suction hose is securely fastened and there are no leaks |
| 3.Pump not primed | 3.Prime the pump by adding oil to near the pump inlet |
Little oil flow | 1.Low voltage supply | 1.Increase the supply voltage to proper levels |
| 2.Excessive suction height or head | 2.Reduce suction height or head |
| 3.Obstruction in the filter strainer | 3.Clear foreign objects, clean filter strainer |
| 4.Vanes worn or gear broken | 4.Replace the vanes or gear |
Q: What's your main products of your company?
A: We specialized in all kinds of water pump(drinking water pump,micro gear pump,high performance diaphragm pump,Marine pump,RV pump )for over 10 years with excellent quality and competitive
Q:How can I choose the most suitable pump?
A: Please tell me your detailed flow rate, voltage, application and so on, then I will match the most appropriate pump for you, or you can choose the exact model in the product manual.If you don’t know the details for the pump, tell us the usage, must suitable model will be recommended.
Q: What's your payment way?
A: Usually we accept T/T ,Western Union or PayPal.
Q: What's your delivery time?
A. 1.The stock samples can be sent to you within 3-5days by international express after received
2.The batch order can be shipped to you in about 10-15days after order confirmation (by air or by sea)
Q: How long is your pump lifetime?
A: Pump lifetime mainly depends on motor lifetime,we have DC brush, brushless, coreless brushless motor For your choice, the pump warranty is 12 months.we can supply 1% spare parts for after service.
