Singflo electric 24v dc diesel fuel pump
- Xiamen Fuzhou Ningbo Shanghai
- Credit Card
You May Like
Product Details
Place of Origin | Fujian, China | Brand Name | Singflo | |
Model Number | YTB-40 | Theory | Electromagnetic Pump | |
Structure | Gear Pump | Usage | Oil | |
Power | Electric | Standard or Nonstandard | Standard | |
Fuel | Diesel | Pressure | High Pressure | |
Application | Other, oil pump |
6pcs oil pump packing with strong seaworthy carton
Product Description
electric 24v dc diesel fuel pump
DC Oil Pump Introduction:
12v/24v oil pump passes a strict performance test for temperature resistance and Anti-Shock, with protection rating of IP55 and high quality. It can make use of car batteries to self-absorb and fast -refuel oil, also use valves at the end of the installation with filters to clean diesel. This pump is sopnisticated designed and applicable to all kinds of engineering machinery, and reaper, tractor and countryside fuel charge.
Features & Benefits:
- Voltage: 12/24v Volt Electric Diesel Pump
- Motor power: 150 Watts
- Maximum flow rate: 10.52 GPM (40 LPM)
Application:
Compatible with Diesel .Oil.Fuel
For use with agricultural machinery, worksite equipment and road-building machines.
Includes:
- 12 Volt pump complete with cables and switch
- 19 ft delivery hose
- Suction hose with foot valve
- Manual nozzle with nozzle 0-60l/min.
- Filter
- Metering with flow range:0-120l/min.
- Iron stainless handler Plat with red color.
YTB40 Series:
voltage (v) | caliber (inch) | suction (M) | Head (M) | Capacity (l/min) | Power (watt) | Speed (RPM) | Dimension(cm) |
12v dc | G3/4'' | 4-5M | 15M | 40L/MIN | 155W | 3900 | 20*15*10CM |
24v dc | G3/4'' | 4-5M | 15M | 40L/MIN | 155W | 3900 | 20*15*10CM |
Fuel Pump Technical Data YB series:
Model | Inlet | Power | Flow |
YB-70 | BSPT/NPT 3/4 1'' | 250w | 0-70l/min |
YB-40A | BSPT/NPT 1'' | 155w | 0-40l/min |
YB-40B | BSPT/NPT 1'' | 150w | 0-40l/min |
YB-60 | BSPT/NPT 1'' | 550w | 0-60l/min |
YB-80 | BSPT/NPT 1'' | 550w | 0-80l/min |
YB-40C | BSPT/NPT 1'' | 120w | 0-40l/min |
Note: Not suitable for low-ignition fuel(such as gasoline, liquefied petroleum gas, alcohol,etc.) transmission.
Failure and Resolution:
Trouble | Reasons | Trestments |
No oil output at first | 1.(+)(-)reversed | 1.(+)(-)correctly attached |
2.oil pipeline leaks | 2.Connect the oil pipe and lock the pipe | |
3.No oil before the pump start | 3.add a little oil pumped | |
Little oil transferred | 1.low supply voltage | 1.Increase the supply voltage,but not exceed the voltage tolerance |
2.excessive suking and head | 2.Adjusting the sucking and the lift ranges | |
3.eyewinker obstrouction in the oil filter | 3,clear foreign body | |
4.Vane wore | 4,replace the vane |
Pictures:
