high capacity CE approved firewood log waste chips briquette extruding machine price

 1. what's the  high capacity CE approved  firewood log waste chips briquette extruding machine

Briquettes are made by grinding Biomass and sawdust into a homogeneous pulp and forming this into a briquette under very high pressure. High pressure & pressing releases one of the natural components of wood - lignin which has the property of becoming liquid at high pressure (temperature) and, as it subsequently cools, it binds the wood together in its new form Briquettes.

2.raw material of the  high capacity CE approved  firewood log waste chips briquette extruding machine

 Almost any biomass can be briquetted. Briquetting plants set so far in India are using Saw Dust, Bamboo dust, Bagasse, Cotton Stalk, Coffee husk, Groundnut Shell, Mustard Husk/Stalk, Pine Needles, Rice Husk, Sugar Mill Waste, Jute waste, Coir pith and other wastes & residues like Castor Shell, Red Gram Stalk, Tobacco stem, Tea Waste, Sander Dust, Tree Bark, Wild Grasses & Shrubs and Sander dust etc. can be also be briquetted individually or in combination without using any binder.

3. what's the final product of the  high capacity CE approved  firewood log waste chips briquette extruding machine

This bio-fuel briquette is 45-80mm in diameter, occurs in the hollow quadrangular or hexagonal cylinder or hollow hexagonal with a 15-20mm hole through the body.

The available shape: square, hexagonal, pentagon, pentagon with edge, hexagon with edge

 The available diameter could be: 50mm,55mm.60mm,65mm.70mm.80mm and so on

The available length could be :20cm,30cm, 40cm, 50cm

The feature of the final product : Specific gravity: 1300—1900kg/m   Calorific value: 4500—5000kcal/kg

 4. what's the specification and models of  high capacity CE approved  firewood log waste chips briquette extruding machine

5.advantage and the structure of the high capacity CE approved  firewood log waste chips briquette extruding machine

 The main machine include the electrical motor, heating system,  switchboard, Temperature control device, rack, transmission lubrication system, the screw propeller, molding barrel, etc.

 details of the  high capacity high capacity CE approved  firewood log waste chips briquette extruding machine

different models and colors of high capacity CE approved  firewood log waste chips briquette extruding machine

project of the  high capacity CE approved  firewood log waste chips briquette extruding machine

the visitors and buyers of the  high capacity CE approved  firewood log waste chips briquette extruding machine

working flowchart of  high capacity CE approved  firewood log waste chips briquette extruding machine

Cushing:

Cushing machine prepare suitable size raw material for biomass

briquetting plant. The required size for briquetting is 3-5mm.

Drying

Drying machine prepare suitable moisture raw material for biomass briquette press.

Moisture of the raw material is important for making good briquettes. The proper moisture of the raw material should be 8-12%.

Briquetting

Biomass briquette machine can process the raw material to briquettes with different shapes and diameter.

for the single machine, we will used the plywood boxes for packing , and  for the whole set briquette machine line we will delivery through the container

A.: The size of material should be no larger than 5*5mm

Q. What is the suitable moisture for briquetting?

A.: The suitable moisture is in the range of 8-13%

Q. What is the final use of the briquettes?

The final briquettes can be fuel for cooking, warming house ,as fuel for boiler and as fuel for BBQ,etc.

Q. How many kgs of waste needed to form 01 kg of briquettes?

A.: For moisture content 8-12% material, 1.2kg of waste can form 1kg briquette

Q. How many Kcal we can get when burning 01 kg of briquettes?

A.: 4500-6000kcl/ kg

Q. Daily capacity of wood briquettes? (How many kgs of briquettes can be produced per day?)

A.: Different model of briquette machine have different capacity. For example 11kw briquette machine, the output of wood briquettes is 1000-1200kg /8 hours (one shift)

Q. Any sub materials/paste we need to add in during the briquetting process?

A.: No, our machine can produce clean briquette without using additives or binders.

Q. Can we make the briquette machine in single phase?

A.: we can't make the machine with single phase motor now.

Q. Which briquette lengths can be stopped

A.: usually the length of briquettes breaks at 450mm, , minimum briquette length is 200mm, no  limit for the maximum length .
