Home > Products > DAHUA Monitor Product > Dahua New Full 2Mp HD Network Auto-Tracking PTZ IR Wipe PTZ Dome Camera SD6AW220/230 -HNI
Dahua New Full 2Mp HD Network Auto-Tracking PTZ IR Wipe PTZ Dome Camera SD6AW220/230 -HNI
Negotiable
/ Piece
1 Piece(Min. Order)
- Shenzhen
- T/T Credit Card
You May Like
-
Dahua HDCVI 1.3apixel HD Network Small IR-Bullet IP Camera POE IPC-HFW2100S
-
Hot Offer Dahua NVR 4/8/16/32CH 1U Network Video Recorder NVR4204/4208/4216/4232
-
Hot Offer Dahua Poe Nvr Nvr5216-p Upgrading Model NVR7216-8P Support 8ch PoE Ports
-
Dahua 5Megapixel Full HD IP Camera POE Small CMOS Network Box Camera IPC-HF3500
-
Hot Selling Dahua ip Box Camera RJ45 IPC-HF3300/3300-W
-
Dahua Cctv Camera With Rj45 Cable/memory Card 2MP Full HD Box IP Camera IPC-HF3200
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Dahua | |
| Model Number | DH-SD6AW220/230-HNI | Style | Dome Camera | |
| Sensor | CMOS | Technology | Pan / Tilt / Zoom | |
| Special Features | Waterproof / Weatherproof |
Product Description
Specifications
Dahua New Full 2Mp HD Network Auto-Tracking PTZ IR Wipe PTZ Dome Camera SD6AW220/230 -HNIPowerful 20x/30x optical zoom
Dahua New Full 2Mp HD Network Auto-Tracking PTZ IR Wipe Dome Camera SD6AW220/230 -HNI
Features
>Powerful 20x/30x optical zoom
>H.264 & MJPEG Three-stream encoding
>Max 60fps 720P and 30fps 1080P resolution
>Defog, DWDR, Day/Night(ICR), Ultra DNR, EIS, Auto iris, Auto focus
>Support Wipe
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
>Max 240°/s pan speed, 360° endless pan rotation
>Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
>Built-in 7/2 alarm in/out
>Support Auto tracking and IVS
>Support intelligent 3D positioning with DH-SD protocol
>Micro SD memory, IP66
>IR Distance up to 150m
Technical Specifications
| Model | DH-SD6AW220-HNI | DH-SD6AW230-HNI | |
| Camera | |||
| Image Sensor | 1/2.8" Exmor CMOS | ||
| Effective Pixels | 1944(H) x 1092(V), 2 Megapixels | ||
| Scanning System | Progressive | ||
| Electronic Shutter Speed | 1/1 ~ 1/30,000s | ||
| Min. Illumination | Color: 0.05Lux F1.6; B/W: 0.005Lux F1.6 | ||
| S/N Ratio | More than 50dB | ||
| Video Output | BNC(1.0Vp-p/75Ω), PAL / NTSC | ||
| Camera Features | |||
| Day/Night | Auto(ICR) / Color / B/W | ||
| Backlight Compensation | BLC / HLC / DWDR (Digital WDR) | ||
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | ||
| Gain Control | Auto / Manual | ||
| Noise Reduction | Ultra DNR (2D/3D) | ||
| Privacy Masking | Up to 24 areas | ||
| Digital Zoom | 16x | ||
| Defog | On / Off | ||
| Wipe | Support | ||
| Lens | |||
| Focal Length | 4.7mm~94.0mm (20x Optical zoom) | 4.3mm~129mm (30x Optical zoom) | |
| Max Aperture | F1.6 ~ F3.5 | F1.6 ~ F4.7 | |
| Focus Control | Auto / Manual | ||
| Angle of View | H: 55.4° ~ 2.80° | H: 65.1°~ 2.34° | |
| Close Focus Distance | 10mm~ 1000mm | 10mm~ 1200mm | |
| PTZ | |||
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -10° ~ 90°, auto flip 180° | ||
| Manual Control Speed | Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s | ||
| Preset Speed | Pan: 240° /s; Tilt: 200° /s | ||
| Preset | 80(DH-SD), 255(Pelco-P/D) | ||
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan | ||
| Speed Setup | Human-oriented focal length/ speed adaptation | ||
| Power up Action | Auto restore to previous PTZ and lens status after power failure | ||
| Idle Motion | Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period | ||
| Time Task | Auto activation of Preset/ Pan/ Scan/ Tour/ Pattern by preset-time | ||
| Protocol | DH-SD (Auto recognition) | ||
| IR Distance | 150m (2 near IR LED+ 8 far IR LED) | ||
| Video | |||
| Compression | H.264 / MJPEG | ||
| Resolution | 1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF (352×288/352×240) | ||
| Frame Rate | Main Stream | 1080P (1 ~ 25/30fps) / 720P(1~50/60fps) | |
| Sub Stream | D1/CIF(1 ~ 25/30fps) | ||
| Bit Rate | H.264: 56K ~ 8192Kbps, MJPEG: 56K ~ 20480Kbps | ||
| Audio | |||
| Compression | G.711a / G.711u(32kbps)/ PCM(128kbps) | ||
| Interface | 1/1 channel In/Out | ||
| Intelligent Function | |||
| Auto Tracking | Single-scene, multiple-scene, panorama-scene | ||
| IVS | Tripwire, Cross Warning Zone, Perimeter Protection, Loitering Detection, Abandoned Object Detection, Missing Object Detection, Illegal Parking, Fast Moving and etc. | ||
| Tracking Trigger Mode | Manual / Auto (alarm triggered) | ||
| Tracking Trigger Event | Targeting, Zoom, Tracking, Recording, Snapshot, Alarm and etc. | ||
| Network | |||
| Ethernet | RJ-45 (10/100Base-T) | ||
| Protocol | IPv4/ IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x | ||
| ONVIF | ONVIF Profile S | ||
| Max. User Access | 20 users | ||
| Smart Phone | iPhone, iPad, Android, Windows Phone | ||
| Auxiliary Interface | |||
| Memory Slot | Micro SD, Max 64GB | ||
| Alarm | 7/2 channel In/Out | ||
| General | |||
| Power Supply | AC 24V/3A (±16%) | ||
| Power Consumption | 20W, 43W (IR on, Heater on) | ||
| Working Environment | -40ºC ~ 70ºC / Less than 90% RH | ||
| Ingress Protection | IP66 | ||
| Dimensions | Φ252(mm) x 385 (mm) | ||
| Weight | 6.75kg | ||
