Wholesale2mp Dahua IP Camera IPC-HDB4200C

Model

DH-IPC-HDB4200C

Camera

Image Sensor

1/2.8” 2Megapixel progressive scan Exmor CMOS

Effective Pixels

1920(H)x1080(V)

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3(4)~1/10000

Min. Illumination

0. 1lux/F1.2(color)

S/N Ratio

More than 50db

Camera Features

Day/Night

Auto(Electronic)/Color/B/W

Backlight Compensation

Off/BLC/HLC/DWDR

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

3D

Privacy Masking

Up to 4 areas

Lens

Focal Length

3.6mm (2.8mm,6mm optional)

Max Aperture

F1.6(F2.0,F1.8)

Focus Control

Manual

Angle of View

H:88°(110°/53°)

Lens Type

Fixed Lens

Mount Type

Board-in Type

Video

Compression

H.264/ MJPEG

Resolution

1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/ CIF(352×288/352×240)

Frame Rate

Main Stream

1080P/720P(1 ~ 25/30fps)

Sub Stream

D1/CIF(1 ~ 25/30fps)

Bit Rate

H.264: 32K ~ 8192Kbps

Audio

Compression

G.711a/G.711u/PCM(-A)

Interface

Built-in Mic(-A)

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour

ONVIF

ONVIF Profile S

Max. User Access

20 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Auxiliary Interface

Memory Slot

Micro SD, Max 64GB

Alarm

1/1 channel In/Out(-A)

General

Power Supply

DC12V, PoE (802.3af)

Power Consumption

Max 3W

Working Environment

-20°C~+60°C, Less than 95% RH

Ingress Protection

IP66

Vandal Resistance

IK10

Dimensions

Φ110mm×54mm

Weight

0.25kg
