Home > Products > Drying Machinery > Bean Dregs Dryer Machine by Professional Manufacturer in China

Bean Dregs Dryer Machine by Professional Manufacturer in China

FOB Price

US$ 8,000 - 350,000 / Set

1 Set(Min. Order)

Port Qingdao/Shanghai or other port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Drum Drying Equipment
Place of Origin	Henan, China	Brand Name	Yuhong
Voltage	220 kva or 380 kva others	Power(W)	5.5-200 kw
Dimension(LWH)	different model different	Weight	3.5- 45 ton
Certification	CE,ISO	Warranty	two years
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

Reliable for runninghigh degree of mechanizationhigh thermal efficiencysimple and excellent Structure

Bean dregs dryer

Brief introduction:

Bean dregs (soybean curb residue) is a kind of bound water, large oil-based materials, water is not easily to remove

We developed a complete machinery of dehydration dryer system for beandregs (soybean curb residue)

Beandregs was dehydrated through high pressure

Most of the water is lost in this way just in a minute

Then the beandregs enter into the dryer system

Beandregs and the dry fresh hot air moving in the opposite direction under the effect of a special scraping wings (pusher plate) and dry-hot wind

This process is a little long, the temperature is relatively low and the material is running slowly

The dryer system is a downstream drying and the outlet temperature is only 40°C

The whole drying process can fully use the thermal energy and the beandregs even heated so the toasted beandregs can have a good color, no burning material and low consumption

type	TD800	TD1000	TD1500	TD2200
Quantity delivered of feed screw	≥800kg/h	≥1200kg/h	≥1800kg/h	≥3000kg/h
Evaporation capacity of moisture	350kg/h	650kg/h	900kg/h	1300kg/h
Rotate speed and power of the rotary drum	3-4rmp,4kw	3-4rmp,5.5kw	3-4rmp,10kw	3-4rmp,15.5kw
Rotate speed and power of the crush axis	150-250rmp,3kw	150-250rmp,4kw	150-250rmp,4kw	150-250rmp,5.5kw
Power of induced draft fan	7.5kw	11kw	15kw	18.5kw
Coal consumption(standard coal)	≤70kg/h	≤110kg/h	≤170kg/h	≤220kg/h
Power consumption	≤10degree/H	≤15degree/H	≤20degree/H	≤30degree/H
area	≥80m2	≥100m2	≥120m2	≥150m2
