high temperature resistance Stainless steel wire mesh
- TIANJIN-CHINA
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Material | Stainless Steel Wire | |
| Type | Weave Wire Mesh | Application | Filters | |
| Weave Style | Plain Weave | Wire Diameter | 0.018 wire diameter to 6 wire diameter | |
| Technique | Woven | Model Number | U-560 | |
| Brand Name | RFMESH |
Product Description
high quality stainless steel wire mesh products, including plain stainless steel wire mesh and stainless steel wire mesh twill. Specific categories are as follows:
Material: SS302, SS304, SS310, SS316, SS316L, SS410, SS410L
Methods: plain weave, twill weave, mat knitting, we can be customized according to customer requirements of some special style. Wire diameter: 0.025mm--6mm
Specifications: plain weave and twill weave from 1 to 540
Size and shape: rolls ( width of 0.914 meters, 1 meters, 1.22 meters, 1.5 meters, 1.8 meters, 2 meters, 6 meters ), and can be washed into the square chip, wafer shape.
Length: 30 meters, or 100 feet, special length can be customized.
Packaging: waterproof paper packaging.
Performance: acid and alkali resistance, high temperature resistance, tensile strength, abrasion resistance
Uses: used in acid, alkali sieve and filter under the environmental conditions, the oil industry as mud mesh, chemical filler mesh, chemical fiber industry to do the sieve, plating industry as pickling network.
Specification List of Stainless Steel Wire Mesh | |||||||
Mesh/Inch | Wire Diameter(mm) | Aperture (mm) | Filtration Area% | Mesh/Inch | Wire Diameter(mm) | Aperture | Filtration Area% |
5 | 1.00 | 4.08 | 64 | 100 | 0.11 | 0.144 | 32 |
6 | 0.90 | 3.33 | 62 | 120 | 0.09 | 0.122 | 33 |
8 | 0.70 | 2.47 | 61 | 150 | 0.065 | 0.104 | 38 |
10 | 0.50 | 2.04 | 64 | 200 | 0.05 | 0.077 | 37 |
12 | 0.50 | 1.62 | 59 | 200 | 0.04 | 0.084 | 47 |
14 | 0.50 | 0.50 | 52 | 250 | 0.04 | 0.062 | 37 |
16 | 0.35 | 1.24 | 61 | 250 | 0.035 | 0.067 | 43 |
18 | 0.28 | 1.13 | 64 | 250 | 0.03 | 0.072 | 50 |
20 | 0.35 | 0.92 | 52 | 300 | 0.04 | 0.045 | 28 |
24 | 0.35 | 0.71 | 45 | 300 | 0.03 | 0.055 | 42 |
28 | 0.35 | 0.56 | 38 | 325 | 0.035 | 0.043 | 30 |
