304 316 Stainless Steel Wire Mesh

FOB Price

US$ 5 - 10 / Meter

100 Meters(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Material	Other, Stainless Steel Wire, stainless steel wire 304 316
Type	Other, Weave Wire Mesh, stainless steel wire mesh	Application	Woven Wire Mesh
Weave Style	Plain Weave	Wire Diameter	0.15-5mm
Technique	Woven	Model Number	stainless steel wire mesh
Brand Name	RFmesh

Stainless Steel Wire Mesh

Contact:Mr John

sales(at)

Mobile:86-13780283262

Our company is a leading manufacturer and exporter in stainless steel wire mesh and

mesh screen.all kinds of wire mesh industry.

As our products' outstanding quality and excellent service,our outputs have been exported to

many countries and regions.

1.Material

high quality stainless steel wire,sus 201,202,304,304L,316,316L

Specification list of Stainless Steel Wire Mesh / Woven Wire Cloth
Meshes Per Linear Inch	Diameter of Wire		Width of Opening		Open Area, %
Meshes Per Linear Inch	Inches	mm	Inches	mm	Open Area, %
100 x 100	0.0045	0.11	0.006	0.15	30.3
120 x 120	0.0040	0.10	0.0043	0.11	26.6
120 x 120	0.0037	0.09	0.005	0.12	30.7
150 x 150	0.0026	0.066	0.0041	0.10	37.4
165 x 165	0.0019	0.048	0.0041	0.10	44.0
180 x 180	0.0023	0.058	0.0032	0.08	33.5
180 x 180	0.0020	0.050	0.0035	0.09	41.1
200 x 200	0.0020	0.050	0.003	0.076	36.0
200 x 200	0.0016	0.040	0.0035	0.089	46.0
220 x 220	0.0019	0.048	0.0026	0.066	33.0
230 x 230	0.0014	0.035	0.0028	0.071	46.0
250 x 250	0.0016	0.040	0.0024	0.061	36.0
270 x 270	0.0014	0.040	0.0022	0.055	38.0
300 x 300	0.0012	0.030	0.0021	0.053	40.1
325 x 325	0.0014	0.040	0.0017	0.043	30.0
325 x 325	0.0011	0.028	0.0020	0.050	42.0
400 x 400	0.0010	0.025	0.0015	0.038	36.0
500 x 500	0.0010	0.025	0.0011	0.028	25.0
635 x 635	0.0009	0.022	0.0006	0.015	14.5

End treatment:

closed end,cut end (barbed end),weld after cut end

Packing

Wrapped with high quality craft paper and then plastic film or in woven bags,for the fine mesh,a wooden case is available
