PIB Self Amalgamating Rubber Tape
- 500000 Roll / Rolls per Month
- Xiamen
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 5 days
You May Like
Product Details
Brand Name | HarshMet | Place of Origin | China | |
Model Number | SFT Series | Material | Other, PIB Rubber | |
Type | Insulation Tape | Application | High Voltage | |
Rated Voltage | 33KV/mm | Tensile Strength | 1.9Mpa |
Product Description
Description
HarshMet HSA-72 isA general-purpose insulating, self-amalgamating tape based on PIB (Polyisobutylene) rubber. Its colour is black..
Sizes
38.1mm×4.57m×0.76mm
19mm×10m×0.51mm
Applications
Product properties and correct application ensure waterproof connections (for fresh and sea water) in a wide range of temperatures.
for jointing and repairing a wide range of power and distribution cables up to10 kV.
for making watertight seals at polyethylene sleeve joints on polyethylene-sleeved telephone cables both above and below ground.
for protection against corrosion at welds and joints and for the waterproofing of many electrical components.
for general-purpose protection and waterproofinG of telecommunications cables.
for insulation, waterproofing and protection of electrical components.
for corrosion protection of metal pipework.
for protection of joints against seawater in marine environments.
for general-purpose DIY temporary repairs.
for waterproofing and protecting cables and components on satellite dishes.
Technical Data
Properties | Typical Value | Test Method |
Thickness | 0.76mm | ASTM D 4325 |
Tensile Strength | 1.9MPa | ASTM D 4325 |
Elongation at break | 800% | ASTM D 4325 |
Fusion | Pass | ASTM D4325 |
Ozone Resistance | Pass | ASTM D 4325 |
UV Resistance | Pass | ASTM D 4325 |
Dielectric Strength | 33KV/mm | ASTM D149:64 |
Dielectric Constant | 2.8 | ASTM D 150:74 |
Heat ageing (130℃ 168H) | Pass | ASTM 4388 |
Ozone ageing | Pass | ASTM 4325 |
UV Ageing | Pass | ASTM 4325 |
Xenon ageing | Pass | ISO 4892-2 |
Notes:
Data in table represent average of test results and are not to be used for specification purposes.
the product user should make their own tests to determine the product's suitability for their intended use.
