Product Details
| Condition | New | Forward Speed(km/h) | 23 | |
| Reverse Speed(km/h) | 38 | Place of Origin | Jiangsu, China | |
| Brand Name | XCMG | Model Number | GR190 | |
| Weight | 15400kg | Dimension(L*W*H) | 8900*2625*3470mm | |
| Certification | ISO | After-sales Service Provided | Overseas service center available |
Product Description
XCMG 180HP Motor Grader GR180 Road Construction Machinery
GR series of motor grader are mainly used in the operation of road surface leveling, ditch digging, slope leveling, bulldozing, scarification and snow removing on the road, airport and farmland. The motor grader is the necessary construction machinery for defense construction, mine construction, urban and rural road construction and irrigation works and farmland improvement.
Features:
•New appearance.
•The adopted articulated frame assists the front wheel to steer, featuring small turning radius and flexibility.
•Electro-hydraulic controlled brake power shift gearbox includes 6 Forward gears, and 3 Reverse gears.
•The adopted international matched hydraulic parts ensure the reliable operation.
• The blade movement is hydraulic controlled fully.
•The rear axle is three-way drive axle with NO-SPIN self -locking differential.
•The reasonable distribution of the adjustable operation panel, seat, lever and instrument guarantees the comfortable and convenient operation.
•The luxury and beautiful cab features wide visibility and good sealing.
•The machine can be equipped with front bulldozing plate, rear scarifier, front harrow and auto-leveling system.
Basic specification | |
Engine model | 6CTAA8.3 |
Rated power/speed | 138kW/2200 |
Dimension(LxWxH) | 8900*2625*3470mm |
Operating weight(Standard) | 15400kg |
Performance specification | |
Travelling speed ,forward | 5,8,11,19,23,38 km/h |
Travelling speed ,reverse | 5,11,23 km/h |
Tractive force(f=0.75) | 79KN |
Max. grade ability | 20% |
Tire inflation pressure | 260 kPa |
Working hydraulic pressure | 16 MPa |
Transmission pressure | 1.3~1.8MPa |
Operating specification | |
Max. steering angle of front wheels | ±50° |
Max. lean angle of front wheels | ±17° |
Max. oscillation angle of front axle | ±15° |
Max. oscillation angle of balance box | 15 |
Frame articulation angle | ±27° |
Min. turning radius using articulation | 7.3m |
Blade | |
Maximum lift above ground | 450mm |
Maximum depth of cutting | 500mm |
Maximum blade position angle | 90° |
Blade cutting angle | 28°—70° |
Circle reversing rotation | 360° |
Moldboard width X height | 3965×610mm |
Shipped by 40HQ container, by removing cabin, tires,etc.
One year warranty, original spare parts support, technical support, oversea service center avaliable.
