Home > Products > Motor Grader > Low Price XCMG Motor Grader GR135 With Rippers For Sale
Low Price XCMG Motor Grader GR135 With Rippers For Sale
US$ 53,000 - 60,000
/ Set
1 Set(Min. Order)
- LIANYUNGANG PORT SHANGHAI PORT
- T/T
You May Like
-
Best Price China XCMG GR135 Mini Motor Grader For Sale
-
Grader Price China Motor Grader GR135
-
China Road Machinery Cheap Price XCMG Motor Grader GR135 For Sale
-
Original Brand New Motor Grader Made in China
-
XCMG 135HP Motor Grader Made in China GR135
-
XCMG 135HP Small Motor Grader GR135 Made In China With Good Price
Product Details
| Condition | New | Forward Speed(km/h) | 42 | |
| Reverse Speed(km/h) | 30 | Place of Origin | Jiangsu, China | |
| Brand Name | XCMG Motor Grader | Model Number | GR135 | |
| Weight | 11000kg | Dimension(L*W*H) | 8015*2380*3050mm | |
| Certification | ISO | After-sales Service Provided | Overseas service center available |
Product Description
Low Price XCMG Motor Grader GR135 With Rippers For sale
Product Description
Parameter
Basic specification | |
|---|---|
| Engine model | 6BT5.9 |
| Rated power/speed | 100/2200kw/rpm |
| Dimension(LxWxH) | 8015×2380×3050mm |
| Operating weight(Standard) | 11000kg |
Performance specification | |
| Travelling speed ,forward | 5,8,13,20,30,42km/h |
| Travelling speed ,reverse | 5,13,30km/h |
| Tractive force(f=0.75) | 61.3KN |
| Max. gradeability | 20% |
| Tire inflation pressure | 300kPa |
| Working hydraulic pressure | 16MPa |
| Transmission pressure | 1.3~1.8MPa |
Operating specification | |
| Max. steering angle of front wheels | ±49° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 16 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 6.6m |
Blade | |
| Maximum lift above ground | 410mm |
| Maximum depth of cutting | 535mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°—70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 3710×610mm |
Packaging & Shipping
Nude package in 40HQ Container, Or, by bulk, Ro-Ro ship. All based on Customer's Requirements.
Our Services
One year warranty, original xcmg spare parts support, oversea service center available, technical support.
Company Information
Customer Visting:
Foreign Fair:
As the professional supplier of XCMG Machines, over 10 year's experience,
we supply Motor Grader, Wheel Loader, Backhoe Loader, Road Roller, Wheel & Crawler Excavator, Bulldozer, Crane, Dump Truck, Milling Machines, etc.
Our main market: Asia, Africa, Australia, EU, America.etc.
Our Goal: Handle right machine to right customer. creat both success.
We will give what you want, if you trust us.
Let's talk details.
